VP-427UHD Quick Start

P/N:

2900- 301156QS

Rev:

Scan for full manual

VP- Start 427UHD Quick Guide

This guide helps you install and use your VP-427UHD for the first time.

Go to www.kramerav.com/downloads/VP-427UHD to download the latest user manual and check if firmware

upgrades are available.

Step 1: Check what’s bin the ox

VP-427UHD HDMI/HDBT Receiver/Switcher/Scaler

1 Bracket set

1 Quick start guide

1 Power adapter and cord

4 Rubber feet

Step 2: VP-Get to know your 427UHD

Feature

Function

IN LED

Lights green when the HDMI blue when HDBT is selected flashes if ™ input is selected, and

no input signal is detected.

HDBT/HDMI Button

Press to select the remote HDBT or the local HDMI source.

HDMI LED ™ OUT Status

Lights green when an HDMI acceptor is connected.

HDBT LINK status LED

Lights green when transmitter and an HDBT link between a the receiver is successfully

established and is active.

ON LED

Lights green when the unit is powered from local 12V DC source and lights blue when the

receiving PoE via HDBT.

MENU Button

Press to enter the menu. When , press to exit one level up.OSD in OSD

ENTER Button

When not in OSD, press ENTER to input status on the display (view the the selected input,

resolution and frame rate, HDCP state and aspect ratio).

When in OSD, press to select and carry out a menu item or to accept a parameter value.

Press and hold together with the increase the speed of parameter– or + to -decrement or

increment, respectively.

Press and hold for about 3 seconds to reset a menu parameter to its default values.

– Button

Press and hold together with the + the output resolution to 1080p ( button to reset default).

In OSD, press to move back through the menu list or to decrement parameter valuea (or

press together with ENTER to speed up parameter decrement).

+ (also Freeze) Button

Press and hold together with the to 1080p (– button to reset the output resolution default).

When not in OSD press to freeze the image: ;

In OSD, press to move forward through the sub-menu list or to increment the parameter

value (or press together with ENTER to speed up parameter increment).

FREEZE LED

Lights green when freezing the image.

HDBT IN RJ-45 Connector

Connects to an HDBaseT transmitter.

HDMI IN Connector

Connect to an HDMI source.

HDMI OUT Connector

Connects to an HDMI acceptor.

AUDIO OUT 5-pin Terminal

Block Connector

Connect to a balanced or unbalanced stereo audio acceptor.

S/PDIF digital audio output

Connect to a digital audio acceptor.

IR 3.5mm Mini Jack

Connect to an IR Sensor (in) or a remoteEmitter (out) to control . device

Feature

Function

Ethernet RJ-45 Connector

Connect via a LAN to a PC to control the VP-427UHD and/or extend Ethernet signals to the

HDBT transmitter via the HDBT IN port.

RS-232 Terminal Block

Connector

Connects to a controller to control the VP-427UHD or to extend RS 232 signals between - the

VP-427UHD and the RS-232 port of the connected HDBT transmitter.

12V DC

+12V DC connector for powering the unit.

The terms HDMI, HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.

Step 3: VP- Mount 427UHD

Install VP-427UHD using one of the following methods:

• Attach the rubber feet and place the unit on a flat surface.

• Fasten a bracket (included) on each side of the unit and attach it to a flat surface

(see www.kramerav.com/downloads/VP 427UHD- ).

• Mount the unit in a rack using the recommended rack adapter

(see www.kramerav.com/product/VP 427UHD- ).

• Maximum mounting height for the device is 2 meters.

• Ensure that the environment (e.g., maximum ambient temperature &

air flow) is compatible for the device.

• Avoid uneven mechanical loading.

• Appropriate consideration of equipment nameplate ratings should be

used for avoiding overloading of the circuits.

• Reliable earthing of rack-mounted equipment should be maintained.

• Maximum mounting height for the device is 2 meters.

Step 4: Connect inputs and outputs

Always switch OFF the power on each device before connecting it to your VP-427UHD. For best results, we recommend that

you always use Kramer high performance cables to connect AV equipment to the - VP-427UHD.

Connect AUDIO OUT

To a balanced stereo

audio acceptor:

To an unbalanced

stereo audio acceptor:

To achieve specified extension distances, use the recommended Kramer cables

available at www.kramerav.com/product/VP 427UHD- .

Using third

- party cables may cause damage!

Step 5: Connect power

Connect the power cord to VP-427UHD and plug it into the mains electricity.

Safety Instructions (See www.kramerav.com for updated safety information)

Caution:

• For products with relay terminals and GPI O ports, please refer to the permitted rating for an external connection, located next to the terminal or in the User Manual.\
