Sivu 1/1
ENEN
ENEN
EN EN
Foreword
Package Contents
Product Overview
Power Adapter ×2 Red/Yellow/Blue Gels ×2
2.4G Remote ×1
② Channel Button "CH+"
③ Channel Button "CH-"
④ Color Temperature Dial
⑤ USB Port
⑥ DC Port
⑦ LCD Screen
⑨ Brightness Dial
⑩ Power Switch
⑪ Angle Adjustment Knob
⑫ Stand Mount Adapter
Locking Knob
⑧ Battery
Compartment
Light Stand ×2
①
① Handle
③
④
⑤
⑦
⑧
⑨
⑩
⑪
⑫
⑥
LED Light ×2
Power Cable ×2
01
2. Remote1. LED Light
Installation Guide
Installation Guide
02
03
This product is a bi-color continuous video light includes a versatile
stand mount adapter for adjustable angles. The included 2.4G remote
enables wireless control of multiple lights simultaneously. It comes with a
light stand, 3 color gels, and a charging port, making it ideal for live
streaming and makeup videos.
06
Specifications
Caution
① Spread the base of the light
stand. Adjust to an ideal
height and secure in position
using the screw knob.
③ Loosen the angle adjustment
knob to adjust the LED light
head to the right angle and
then tighten the knob.
② Mount the LED light on the
top of the light stand and
tighten the retention knob
on the support bracket.
④ Insert a color gel into the gel
slot. Rotate the color gel until
it clicks in place.
Note: The color gel included in the package has two sides. Make sure to
place the side with the "outside" marking facing outward when using it.
Color Temperature Setting Brightness Adjustment
Remote Control Guide
Remote Control Guide
04
1. Basic Operation of the Remote
① Remove the battery compartment cover and insert two AAA batteries,
ensuring the +/- polarity markings are correct, then replace the cover.
② Press the " " button to turn the remote on/off.
2. Selecting Channels on the Remote
① Turn the remote on.
② Press "M" button, and the channel icon will
flash on the LCD screen.
③ Press "+" and "-" buttons to select one of the
11 channels (1‒10 and 88). Press the "M" button
again after selection to confirm.
05
3. Using the Remote to Control One LED Light
Set the LED light and the remote on the same channel (for example,
CH: 1), then use the remote to control the LED light.
4. Using the Remote to Control Multiple LED Lights
Set LED lights on any channel from CH: 0 to CH: 10, then set the remote
on CH: 88 to simultaneously control all the lights.
5. Using the Remote to Control Multiple Groups of LED Lights
① Set the first group of lights on the same channel (for example, CH: 01), set
the second group of lights on another channel (for example, CH: 02), and
so forth.
② When the remote is set on CH: 01, it can control all the lights in the first
group. When the remote is set on CH: 02, it can control all the lights in
the second group.
③ When the remote is set on the blanket channel of CH: 88, it can control
all groups of lights, irrespective of the channel set.
6. Using the Remote to Adjust Brightness and Color Temperature
① Turn on the LED light and the remote, then set them on the same
channel.
② Press the "+" button to increase color temperature and "-"
button to decrease.
③ Press the " " to increase the brightness level and the " "
button to decrease.
④ Long press the " " button to make the remote enter or exit standby
mode.
1. Avoid dropping the product or subjecting it to strong impact.
2. Do not directly stare at the lights as it may harm your vision.
3. Keep the product away from any flammable or explosive materials.
4. Avoid using the product in rainy or humid environments.
5. Disconnect the power when the product is not in use.
6. If the product will not be used for an extended period, store it in a dry and
well-ventilated place, away from heat sources and magnets.
7. After the product has cooled down, store it in a bag to prevent damage
to the LEDs.
DC 15V
Model NW48 Ⅱ
Input
Maximum Power 36W
Maximum Illuminance
CRI
Brightness 0%-100%
Color Temperature 2900K~7000K
Channels 0~10
2.4G Remote Power Source 2 x AAA battery
5200Lx@0.5m
CRI 95+
Power Supply (Batteries)
Operating Guide Operating Guide Operating Guide
Insert compatible batteries
into the compartments.
电池
Power On/Off
To power the light using
batteries, press the "-" end
to switch it on. The LCD
screen will activate and
display the battery status.
When the light is powered
by the power adapter,
press the "=" end to
switch it on. The LCD
screen will also turn on
when the light is activated.
To turn off the light, simply
move the switch into the
"O" position.
LCD Screen
Channel Button
Brightness "+" ButtonChannel/Color
Temperature "+" Button
Channel/Color
Temperature "-" Button
Brightness "-" Button
Power/Standby Button
Brightness Adjustment
Turn the brightness dial to
adjust from 0 to 100%.
Turn the color temperature
dial to adjust between
2900K to 7000K.
Press "CH+"/"CH-" to select
channels from 0 to 10.
Color Temperature
Adjustment
Channel Selection
※ "CH: 0" on the light is a backup channel. It can only be controlled
by "CH: 88" on the remote.
②
Power Supply (Power Adapter)
To power the light, use the DC
15V power adapter provided.
Connect one end of the adapter
to the light's DC port and plug
the other end into a wall
socket for power supply.
①
②
③
DC13-19V
0%
100%
2900K
7000K
DC13-19V
0%
100%
2900K
7000K
Compatible Batteries
NP-F550 NP-F750 NP-F970
*Batteries are not included.
Separate purchase required.
Note: This light has a higher power output (series circuit), so it requires two
batteries at the same time.
DC13-19V
0%
100%2900K
7000K
CH.
DC13-19V
0%
100%2900K
7000K
CH.
DC13-19V
0%
100%
2900K
7000K
CH.
CH.
CH.
CH.
CH.
CH.
Product Overview
Remote Control Guide Remote Control Guide
