Sivu 1/39
LEDA7001NW-B
LEDA7002NW-B
LEDA7003NW-B
LEDA7005NW-B
USER MANUAL 2
HANDLEIDING 7
MODE D'EMPLOI 12
MANUAL DEL USUARIO 17
BEDIENUNGSANLEITUNG 22
INSTRUKCJA OBSŁUGI 27
MANUAL DO UTILIZADOR 32
LEDA7001NW-B/LEDA7002NW-B/LEDA7003NW-B/LEDA7005NW-B
V. 01 05/12/2018 2 ©Velleman nv –
USER MANUAL
1. Introduction
To all residents of the European Union
Important environmental information about this product
This symbol on the device or the package indicates that disposal of the device after its
lifecycle could harm the environment. Do not dispose of the unit (or batteries) as
unsorted municipal waste; it should be taken to a specialized company for recycling.
This device should be returned to your distributor or to a local recycling service. Respect
the local environmental rules.
If in doubt, contact your local waste disposal authorities.
Thank you for choosing Perel! Please read the manual thoroughly before bringing this
device into service. If the device was damaged in transit, do not install or use it and
contact your dealer.
2. Safety Instructions
Read and understand this manual and all safety signs before using this appliance.
This device is not suitable for ordinary lighting in household room illumination.
Respect a minimum distance of 1 m between the device’s light output and any
illuminated surface.
IP65
IP class . This appliance is suitable for outdoor use. 65
This device can be used by children aged from 8 years and above, and persons with
reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning the use of
the device in a safe way and understand the hazards involved. Children shall not
play with the device. Cleaning and user maintenance shall not be made by children
without supervision.
For non-replaceable light sources:
The light source of this luminaire is not replaceable; when the light source reaches
its end of life the whole luminaire shall be replaced.
If the external flexible cable or cord of this device is damaged, it shall be exclusively
replaced by the manufacturer or his service agent or a similar qualified person in
order to avoid a hazard.
Do not use the luminaire with a cracked or broken protective shield. Disconnect
immediately from the power source. The protective shield is not replaceable.
Do not use the appliance in explosive atmospheres or in the presence of flammable
materials, liquids, gases and dust.
Protect this appliance from heat sources such as radiators, heat registers, stoves, or
other appliances (including amplifiers) that produce heat.
Keep a switched-on appliance at a distance of at least 1 m from walls and other
objects.
Do not look directly into the light source and do not shine directly into the eyes.
LEDA7001NW-B/LEDA7002NW-B/LEDA7003NW-B/LEDA7005NW-B
V. 01 05/12/2018 3 ©Velleman nv –
3. General Guidelines
Refer to the Velleman ® Service and Quality Warranty on the last pages of this
manual.
All modifications of the device are forbidden for safety reasons. Damage caused by
user modifications to the device is not covered by the warranty.
Only use the device for its intended purpose. Using the device in an unauthorised
way will void the warranty.
Damage caused by disregard of certain guidelines in this manual is not covered by
the warranty and the dealer will not accept responsibility for any ensuing defects or
problems.
Nor Velleman nv nor its dealers can be held responsible for any damage
(extraordinary, incidental or indirect) of any nature (financial, phys– ical…) arising
from the possession, use or failure of this product.
Keep this manual for future reference.
4. Installation
Guidelines
The construction to which the device is attached should be able to support 4 times
the weight of the device for one hour without deformation.
Never stand directly below the device when it is being mounted, removed or
serviced. Have a qualified technician check the device once a year and once before
you bring it into service.
Overhead mounting requires extensive experience: calculating workload limits,
determining the installation material to be used… Have the material and the device
itself checked regularly. Do not attempt to install the device yourself if you lack
these qualifications as improper installation may result in serious injuries.
This device is not suitable for dimming.
Distances
Keep at least 20 cm distance at the top and 30 cm on either side.
Respect a minimum distance of 1 m between the device’s light output and any
illuminated surface.
Location
You can adjust the detection area according to your needs: turn the device to the
left or right and aim it up or down. Note that the detector is much more sensitive to
objects moving across the detection area than it is to objects coming straight at it.
This is a very important consideration when selecting the mounting location.
Please avoid installing the floodlight upside-down in order to ensure its
watertightness.
The floodlight should be fixed to a stable outdoor wall made of a non-flammable
material approximately between 0.5-3.0 m above the ground and at an angle of
± 60°, preferably in a location under eaves where the unit is protected from the
elements and shielded from direct sunlight.
Do not block the front of the detection window and make sure the detection area
holds no moving objects.
Do not install the device close to air conditioning vents, radiators, etc.
