Page 1
Professional Passive Speakers
iSK SPEAKER SERIES
iSK12 iSK15 iSK215 iSK18SBI I I
iSK SPEAKER SERIES Data Sheet 03/03/2012
Informaon in this document is subject to change without noce.
With its signature vercal curvatures, thick foamed grille, and ergonomic metal handles, the studio-tuned iSK establishes itself as the
new segment benchmark. The iSK’s new 1.8’’ pure titanium compression tweeters gracefully extends beyond 22kHz and long-throw
woofers reaches lower F0’s than other woofers on the market. The iSK series is the most versale in its class with 35mm standard pole
mounts, 45° oor monitor posion for two-way models and M10 suspension points on the Deluxe models. Finally, the iSKs are incredibly
heavy-duty with either tough an-scratch paint (Deluxe) or professional-grade carpeng (Original). The iSK models are constructed from
20mm thick Grade-A MDF panels, engineered for an unsurpassed audio response, sensaonal power handling, and extensive mounng
possibilies, the iSK establishes a new benchmark.
4RMS power rangs cered and tested using the IEC 268 torture test
4Thick 20mm Grade-A MDF with internal bracing system increases structural strength
4New 1.8’’ pure tanium compression tweeter paired with Phonic’s proprietary Wing-Guide™ horn
delivers smooth, transient highs beyond 22kHz
4Wide 90°x70° dispersion angle
4New long-throw composite woofers oer among the lowest F0’s in market
4Professional Speakon In/Out Connecons
4Serve as oor monitor when lted on the side (iSK12/15)
4Thick 1.3mm/1.6mm foamed grille (iSK215/18SB)
4Durable and ergonomic metal handles
4Also available with a tough an-scratch paint nish (“Deluxe” models)
Features
Descripon
iSK12
700W 12’’ Passive 2-way Stage Speaker /
Floor Monitor
iSK15
700W 15’’ Passive 2-way Stage Speaker /
Floor Monitor
iSK215
1400W Dual 15’’ Passive 2-way Stage
Speaker
iSK18SB
1000W 18’’ Passive Subwoofer
Page 2
Professional Passive Speakers
iSK SPEAKER SERIES
iSK SPEAKER SERIES Data Sheet 03/03/2012
Informaon in this document is subject to change without noce.
iSK12 iSK15 iSK215 iSK18SBI I I
Specicaons
Dimensions
iSK 12 (Deluxe) iSK 15 (Deluxe) iSK 215 (Deluxe) iSK 18SB (Deluxe)
System Specicaons
System Type 2-way 2-way 2-way Subwoofer
Frequency Response
(+/- 3dB) 50Hz - 22kHz 40Hz - 22kHz 38Hz - 22kHz 38Hz - 250Hz
RMS(IEC 268) / Music / Peak 350/700/1400W 350/700/1400W 700/1400/2800W 500/1000/2000W
Sensivity 1w@1m 98dB 98dB 99dB 99dB
System Impedance 8ohm 8ohm 4ohm 4ohm
Low Frequency Driver
Driver Size 305mm/12in 380mm/15in 380mm/15in 470mm/18in
Diaphram Material Paper/Fiber Composite Paper/Fiber Composite Paper/Fiber Composite Paper/Fiber Composite
Voice Coil Diameter 66mm/2.6in 66mm/2.6in 66mm/2.6in 100mm/4.0in
High Frequency Driver
Voice Coil Diameter 45mm/1.8in 45mm/1.8in 45mm/1.8in -
Diaphram Material Pure Titanium Pure Titanium Pure Titanium -
Horn Design Wing-Guide" Wing-Guide" Wing-Guide"" -
System Dispursion 90°x70° 90°x70° 90°x70° -
Crossover
Type 2-way full range 2-way full range 2-way full range Subwoofer
Protecon Bulb Protecon Bulb Protecon Bulb Protecon Bulb Protecon
Input/Outputs
Connectors Speakon x 2 Speakon x 2 Speakon x 2 Speakon x 2
Enclosure
Shape/Type Stage Speaker
and Stage Monitor
Stage Speaker and
Stage Monitor/Stage Speaker Stage Speaker Stage Speaker
Suspensio/Mounng Three M10 Suspension
point (deluxe)
Three M10 Suspension
point (deluxe) - -
Box Protecon/Finish Thick-Carpet/Paint-Coat(deluxe) Thick-Carpet/Paint-Coat(deluxe) Thick-Carpet/Paint-Coat(deluxe) Thick-Carpet/Paint-Coat(deluxe)
Wood Thickness 20mm/0.8in
(16mm/0.64in)
20mm/0.8in
(16mm/0.64in)
20mm/0.8in
(16mm/0.64in)
20mm/0.8in
(16mm/0.64in)
Grille Gauge 1.3mm 1.3mm 1.6mm 1.6mm
Wood Type Premium MDF Premium MDF Premium MDF Premium MDF
Bracing Stabilty Bracing System Stabilty Bracing System Stabilty Bracing System Stabilty Bracing System
Sound Ports 50mm x 2pcs 60mm x 2pcs 60mm x 4pcs 146 (Diameter) x159 (Length) x 2pcs
Pole Mount 35mm Pole Mount 35mm Pole Mount - 35mm Pole Mount
Handles Egronomic Metal Handles Egronomic Metal Handles Egronomic Metal andles Egronomic Metal Handles
Physical
Unit Dimensions
(HxWxD)
627x395x370mm /
24.7x15.5x14.6in
717x460x435mm /
28.2x18.1x17.1in
1170x460x435mm/
46.1x18.1x17.1in
535x620x620mm /
21.1x24.4x24.4in
Weight 23.5kg/51.7lbs 28.5kg/62.7lbs 50kg/110lbs 47kg/103.4lbs
Weatherproof Bags
he iSK's specially constructed
eatherproof bags protect your
peakers while on the road.
ain, sleet or snow, your iSK
peakers are able to go with
ou on tour regardless of the
orecast.
Back Panel
