Sivu 1/2
Features
USB Type-C - Female
Introduction
This premium Rocstor is a traveling charger with PD3.0(5V3A/9V3A/15V3A/20V5A). Use
travel charger connect to the devices (Mobile phone, Note book, MP3 Players, etc) that
can rely on USB cable for power! This adapter plugs into electric outlet to become a
powered USB port. It is helpful in long time journey and convenient for business!
1. Plug the DC connector of power adapter into a socket.
2. Plug one USB connector of the cable into the interface of the charger and plug the
other connector of the cable into the electronic device (Apple Air, Google
Chromebook, iPhone, Samsung mobile phone,MP3,PC, etc.)
3. Please pull the USB connector out after the electronic equipment's fully charged.
Operation Notes
1. For optimum performance, use the power station according to the user manual.
2. Plug the power adapter into socket whose voltage range should be 100~240VAC.
3. Please unplug the power adapter after using.
4. Do not use the power station with an electronic product which is not in conformity
with the specications, so as to avoid any problems caused by specication
mismatching.
5. It’s normal that power adapter will be a little overheated in the use process.
6. When the power station stops working under over-current, over- temperature or
short-circuit protection, please unplug the device after it automatically returns to
work, then you need to check whether the device is compatible with this charger.
7. Do not let the power station close to re, such as stove, candles and etc.
8. Do not let the power station soak into liquid, such as swimming pool, bathtub, etc.
9. Do not wash the power station with corrosive cleaner.
Output:
Specication
Operation Procedures
Package Contents
Before attempting to use this unit, please check the packaging and make sure
the following items are contained in the Packaging:
• Main unit x1
• User Manual x1
Input/Output
Input 100-240VAC 50/60Hz
Output 5V/3A, 9V/3A, 12V/3A, 15V/3A, 20V/3.25
Protection
Over current Protection Yes
Short circuit Protection Yes
Over temperature protection Yes
Over Load Protection Yes
Performance
Ripple And Noise ≥200mv
Eciency ≥91%
Line Regulation ± 5%
Mechanical
Color White
Size (56.2 x 50 x 28.7) mm - (2.2 x 1.9 x 1.1) in
Weight 105 gr - 0.26 lbs
Environmental
Operating Temperature Range 0~25°C
Storage Temperature Range -20 ~ 80°C
Operating Relative Humidity 90 ~ 95% RH
Accessory User Manual
Warranty 1-Year
®
Congratulations
Thank you for purchasing this premium Rocstor product. For optimum performance and
safety, please read these instructions carefully before connecting, operating or using this
product. Please keep this manual for future reference.
Rocstor Premium 65W Smart USB-C®
Power Adapter
User Manual
Y10A246-W1
• Allows100-240VACof input voltage.
• USB-C output: 5V/3A.9V/3A,12V/3A,15V/3A,20V/3.25A
• Accurate limited current output.
• Over current protectionwith Auto-recovery.
• Overload protection and over voltage protection.
• Short circuit protection with Auto-recovery.
• Over temperature protection with Auto-recovery.
• Intelligent LED for PD charging.
• Portable and convenient to use.
Technical Support / RMA
Hours: 9:00 am - 5:00 pm PST
Monday to Friday (except holidays)
Tell: +1 (818) 727-7000
( )National and international
Fax: +1 (818) 875-0002
Email: support@Rocstor.com
Support
Warranty Information
Technical support is available to all the registered users of Rocstor products.
Safety Information:
Connection Diagram
© 2021 Rocstroge, Inc. Rocstor is registered trademark of Rocstorage, Inc. Apple®, the Apple logo, Mac®,
MacBook®, MacBook Pro®, MacBook Air®, iPad®, iPad Air®, iPad mini®, iPad Air®, iPhone®, MacOS® are
registered trademarks of Apple, Inc. Google® and Chromebook™ are registered trademarks of Google,
LLC. Microsoft® and Surface® are registered trademarks of Microsoft corporation. USB Type-C® and
USB-C® are registered trademark of USB Implementers Forum.
WARNING: Please follow these safety instructions. Failure to do so may result damages or injury.
It is normal that the Rocstor adapter becomes very warm during use.
Please note that:
continuous contact with warm surfaces for extended time may cause discomfort or injury. In order to
reduce the possibility of overheating or heat-related injuries, always allow needed ventilation around
the Rocstor adapter and use care when handling it. Avoid instances where your skin is in extended
contact with the hub when plugged into the host computer. It is not recommended to sleep with the
adapter when plugged into a host computer. Avoid placing the hub adapter under a pillow, blanket,
or your body when connected to a host computer. If you have a medical condition that aects your
ability to detect heat against the body, extra care should be used. Never use the adapter in locations
with water, such as a sink, bathtub, or shower stall. Never connect or disconnect the adapter with wet
hands.
!
Limitation of Liability
In no event shall the liability of Rocstorage, Inc. and Rocstor (or their ocers, directors, employees or
agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or
otherwise), loss of prots, loss of business, or any pecuniary loss, arising out of or related to the use of
the product exceed the actual price paid for the product. Some states do not allow the exclusion or
limitation of incidental or consequential damages. If such laws apply, the limitations or exclusions
contained in this statement may not apply to you.
Warranty Information
This product is backed by a (1) one-year warranty. Rocstor warrants its products against defects in
materials and workmanship for the periods noted, following the initial date of purchase. During this
period, the products may be returned for repair, or replacement with equivalent products at our
discretion. The warranty covers parts and labor costs only. Rocstor does not warrant its products from
defects or damages arising from misuse, abuse, alteration, or normal wear and tear.
USB Type-C Cable
