Sivu 1/9
BW120 PWM FAN
Manual Anleitung Manuel Manuale dell'utente  
Handleiding Instrukcja Használati útmutató Příručka 
Руководство пользователя El Kitabı 使用說明
Specifications
General:
Fan Speed:
450~1,400 rpm ± 10%
Bearing Type:
Fluid Dynamic Bearing
Max. Airflow: 89.06 m³/h
Max. Air Pressure: 1.31 mm-H2O
Max. Noise Level: 28 dB(A)
MTBF:
Min. 50,000 Hours
Dimensions (L x W x H):
120 x 120 x 25 mm
Weight incl. Fixed Cable: 132 g
Cables and Connectors:
Fan Connector:
4-Pin PWM
Fan Cable Length:
450 + 100 mm
Electrical Specifications:
Rated Voltage: 12 V
Rated Current: 0.15 A
Rated Power: 1.8 W
Start Voltage: 7 V
Spezifikationen
Allgemein:
Lüfterdrehzahl:
450~1.400 U/min ± 10 %
Lagertyp:
Hydrodynamisches Gleitlager
Max. Volumenstrom: 89,06 m³/h
Max. Luftdruck: 1,31 mm-H2O
Max. Geräuschentwicklung: 28 dB(A)
Durchschnittliche Lebensdauer:
Min. 50.000 Stunden
Abmessungen (L x B x H):
120 x 120 x 25 mm
Gewicht inkl. fixiertem Kabel: 132 g
Kabel und Anschlüsse:
Lüfteranschluss:
4-pol. PWM
Länge Lüfter-Kabel:
450 + 100 mm
Elektrische Daten:
Nennspannung: 12 V
Nennstrom: 0,15 A
Nennleistung: 1,8 W
Startspannung: 7 V
01
Spécifications
Especificaciones
General:
Velocidad del ventilador:
450~1.400 rpm ± 10 %
Tipo de rodamiento:
Rodamiento dinámico líquido
Máx. flujo de aire: 89,06 m³/h
Máx. presión atmosférica:
1,31 mm-H2O
Máx. nivel de ruido: 28 dB(A)
MTBF: Mín. 50.000 horas
Dimensiones (L x An x Al):
120 x 120 x 25 mm
Peso incl. cable fijo: 132 g
Cable y conectores:
Conector del ventilador:
4 pines PWM
Longitud del cable del ventilador:
450 + 100 mm
Especificaciones eléctricas:
Voltaje nominal: 12 V
Corriente nominal: 0,15 A
Potencia nominal: 1,8 W
Voltaje inicial: 7 V
Especificações
Geral:
Velocidade da ventoinha:
450~1.400 rpm ± 10 %
Tipo do rolamento:
Rolamento de fluido dinâmico
Máx. Fluxo de ar: 89,06 m³/h
Máx. Pressão de ar:
1,31 mm-H2O
Máx. Nível de ruído: 28 dB(A)
MTBF: Mín. 50.000 horas
Dimensões (C x L x A):
120 x 120 x 25 mm
Peso incl. o cabo fixo: 132 g
Cabo e conectores:
Conector da ventoinha:
4-pin PWM
Comprimento do cabo da ventoinha:
450 + 100 mm
Especificações Eletricas:
Tensão nominal: 12 V
Corrente nominal: 0,15 A
Potência nominal: 1,8 W
Tensão inicial: 7 V
03
Specificaties
