Sivu 1/29
VXP Series
Professional Loudspeake
Operation Manual
2
VXP Series Operation Ma
Important Saf
SAFETY WARNING
Permanent disconnection from the mains supply is achieved by removing the power cord from the mains supply outlet.UNDER NO CIRCUMSTANCES SHOULD YOU BREAK THE POWER USING THE powerCON CONNECTOR.
SAFETY WARNING
Do not remove any covers, loosen any ฀xings or allow items to enter any aperture
SAFETY WARNING
Objects ฀lled with liquids should not be placed on this apparatus.
SAFETY WARNING
The rear heatsink on this product gets hot. Avoid direct skin contact during operation and for at least 5 minutes after power has been isolated.
AVERTISSEMENT DE SECURITE
Pour déconnecter l’appareil de l’alimentation principale de façon permanente, débranchez le connecteur du câble fourni à l’arrière de l’appareil.
AVERTISSEMENT DE SECURITE
Ne retirez pas les couvercles, ne desserrez pas les ฀xations et ne laissez aucune pièce s’introduire dans les ouvertures.
AVERTISSEMENT DE SECURITE
Ne placez pas d’objets contenant du liquide à proximité de l’appareil.
AVERTISSEMENT DE SECURITE
Le radiateur arrière de cet appareil devient chaud. Evitez tout contact direct avec la peau pendant le fonctionnement et au moins 5 minutes après la mise hors tension de l’appareil.
Important Safet y Instructions
1. Read these instru2. Keep these instruc3. Heed all warning4. Follow all instruc5. Do not use this ap6. Clean only with a7. Do not block any with the manufactur8. Do not install nea registers, stoves, or produce heat.9. Do not defeat the plug. A polarized pl other. A grounding prong. The wide bla safety. If the provid electrician for repla10. Protect the power particularly at plugs where they exit from11. Only use attachm manufacturer. 12. Use only with the speci฀ed by the man When a cart is used apparatus combinat13. Unplug this appa for long periods of t14. Refer all servicin required when the a such as power-supp spilled or objects ha has been exposed to normally, or has bee
Tepresence of uninsulated "dangerous voltage " within theproduct's enclosure that may be of su฀cient magnitudetTioperating and maintenance (servicing) instructions in thel
VXP Series Operation Manual rev 3.0.0
3
Installation Instructions
1. THIS PRODUCT MUST BE EARTHED. Use only a ฀exible
cable or cord provided with a green or green and yellow core
which must be connected to the protective earthing terminal
of the detachable Neutrik ‘powerCON’ type NEC3FCA
connector (Tannoy part number 3461 0919) as supplied with
the equipment. The other end of the green or green and yellow
conductor must be connected to the earthing pin of a suitable
mains plug or the earthing terminal of the installation. The cord
must be of maximum length 7.5 meters, rated SJ, SJT, or SJE,
10A minimum and be marked VW-1.
2. The electrical power connection to this product is only to
be made via a detachable Neutrik ‘powerCON’ type NEC3FCA
connector (Tannoy part number 3461 0919) as supplied with
the equipment. Wiring to this connector must be made
by suitably quali฀ed personnel and must comply with all local
requirements.
3. Do not install this equipment in an enclosed space. Do not limit
free ventilation and movement of air around the back panel.
Ensure that there is at least 100 mm (4”) of space around all
sides of the product for ventilation. Only use attachments and
accessories approved or speci฀ed by Tannoy.
FOR CUSTOMERS IN EUROPE
This product complies with both the LVD (electrical safety)
73/23/EEC and EMC (electromagnetic compatibility) 89/336/
EEC directives issues by the commission of the European
community. Compliance with these directives implies conformity
with the following European standards:
EN60065 Product safety
EN55103-1 EMC emissions
EN55103-2 EMC immunity
This product is intended for the following electromagnetic
environments: E2; E3 & E4. Environment E1 (domestic) is
speci฀cally excluded.
FOR CUSTOMERS IN THE USA & CANADA
This product has been tested for electrical safety and
complies with:
UL60065 7th edition
CA/CSA C22.2 No.60065-03 EMC
This equipment has been designed to comply with the limits for
a Class A digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a
commercial environment.
Industry Canada Class A emission compliance statement:
This Class B digital apparatus complies with Canadian ICES-003.
Avis de conformite’ a’ la re’glementation d’Industrie Canada, cet
appareil nume’rique de classe A est conforme a’ la norme ICES-
003.
Table of Contents
4 VXP Series Operation Manual rev 3.0.0
Table of Contents
1. Introduction 5
2. Unpacking and Visual Checks 6
2.1. Preliminary Recommendation ฀6
3. Rear Interface Panel 7
4. Operation 8
4.1. Preliminary Recommendation ฀9
4.2. Auto and Manual Power Modes ฀9
4.3. Cooling ฀9
4.4. LED Functions ฀9
4.5. Audio Connections ฀10
4.6. Gain Structure ฀10
5.7 Limiters ฀10
5. Equalisation 11
6. Arraying 12
7. Dimensions 13
8. Rigging and Safety Procedures 18
9. Service Parts & Accessories 19
10. Technical Speci฀cations 20
11. Warranty 29
12. Declaration of Conformity 30
1. Introduction
VXP Series Operation Manual rev 3.0.0
5
1. Introduction
Designed and engineered in a unique partnership between Tannoy and Lab.gruppen, the VXP Series
comprises a range of powered (active) loudspeakers for demanding professional and commercial sound
applications. Each incorporates acclaimed Dual Concentric™ driver technology in tandem with on-board
powering by Lab.gruppen’s IDEEA™ (IntelliDrive Energy Ef฀cient Ampli฀er) module.
All VXP Series loudspeakers are designed to perform with very high ef฀ciency and exceptionally low distortion,
even when operating near peak output levels. At the heart of VXP Series is the latest genearation of Dual
Concentric loudspeaker technology, which combines a high frequency driver and a low-mid driver on a
common axis to create a true point source for all reproduced sounds. Dual Concentric eliminates the time
alignment problems inherent with all separated driver enclosures, ensuring outstanding de฀nition, detail and
intelligibility at all points in the listening area.
Paired with Dual Concentric driver technology is the new IDEEA powering module from Tannoy’s sister
company in Sweden, Lab.gruppen. At the heart of the IDEEA module is a patented Class D output stage
capable of sustained high power levels with very low distortion – all with near 90% ef฀ciency. A universal
switching power supply accepts any mains voltage from 100 - 240 V (+/- 10%) at 50 Hz or 60 Hz through the
appropriate IEC cord. The power control selector supports two operational modes: in Auto mode, the system
turns on with signal present and turns off after 20 minutes of no signal input; manual mode allows the speaker
to be turned on and off as required. Also provided is a switchable 90 Hz high-pass ฀lter for use when adding
a subwoofer. To ensure a long and trouble-free service life, IDEEA modules incorporate extensive features to
safeguard internal circuits and the driver complement.
Within the VXP Series, system designers can choose from a variety of sizes, power levels and coverage
patterns to suit particular requirements. For extended bass performance, models with the “.2” designation
augment the Dual Concentric LF driver with a second matched LF driver. The “HP” designation indicates
extended power handling capabilities, while the “Q” suf฀x indicates incorporation on the new Q-Centric
Waveguide (QCW™) for applications requiring an asymmetrical coverage pattern. The QCW horn can be
rotated in a matter of minutes, allowing placement of the 75 x 40 degree pattern with either horizontal or
vertical orientation.
All VXP models are enclosed in rugged birch plywood enclosures, with larger models equipped with double-
chamfered Integrip™ recessed handles for easy one- or two-handed carrying. Re฀ecting Tannoy and Lab.
gruppen’s common reputation for reliability, all VXP Series loudspeakers are backed by a ฀ve-year warranty.
3. Rear Interface Panel
VXP Series Operation Manual rev 3.0.0
7
3. Rear Interface Panel
XLR FEMALE AUDIO INPUT - This is a lockable
XLR line input socket for connection to the audio
source. Fully balanced: pin 2 hot (+), pin 3 cold (+),
& pin 1 ground.
XLR MALE AUDIO LINK - This is a lockable XLR
line output socket to link additional speakers.
Fully balanced: pin 2 hot (+), pin 3 cold (+),
& pin 1 ground.
POWER MODE SWITCH (right) – Selects AUTO or
MANUAL power on/off mode.
HPF MODE SWITCH – Inserts or removes
90 Hz high pass ฀lter.
LEVEL CONTROL – Recessed potentiometer for
adjustment of speaker volume.
LED INDICATORS – Top to bottom:
Limit protect indicates activity of built-in speaker
protection limiter.
Signal indicates when audio signal is present at
the input.
Power state LED (Red) = StandBy
Power state LED (Green) = Active
Power state LED (Amber) = Temp protection active.
Since we have the auto power on/off functionality,
there are mulitple ways for this LED to change colour
(Red/green).
ROCKER POWER SWITCH - Supplies AC power
on to the unit (100 V - 240 V)
AC MAINS CONNECTOR - Neutrik powerCON
mains connector (mating connector supplied)
XLR FEMALE
AUDIO INPUT
XLR MALE
AUDIO LINK
POWER MODE SWITCH ROCKER
POWER SWITCH
HPF MODE SWITCH AC MAINS
CONNECTOR
LEVEL CONTROL
LED INDICATORS
4. Operation
VXP Series Operation Manual rev 3.0.0
9
4.1. Preliminary Recommendation
VXP products are equipped with Neutrik powerCON mains connectors which mate with the Neutrik NAC3FCA
Cable connector, quick lock with a securing lever for power-in. This AC mains connector is supplied with each
VXP product.
The IDEAA™ module in VXP loudspeakers has a universal power supply. It will operate on any AC mains supply
from 70 V to 265 V (+/- 10%) at 50 or 60 Hz, although with reduced power output capability at the low voltage
extremes 100-240 V (+/-10%). The module will continue to function down to 70 Vac, but with reduced output
power capabilities. This allows continued operation even when using long, thin power cables, or when powered
from portable generators that are unable to maintain full nominal voltage.
4.2. Auto and Manual Power Modes
VXP loudspeakers are designed to meet the requirements of the Energy Star 2.0 speci฀cation. The IDEEA
module is highly ef฀cient in operation, regardless of levels or program material, and has a STANDBY power
consumption of less than 0.5 W. It also offers two modes for power on/off.
AUTO mode – This is the default mode as delivered. AUTO engages the Auto Power Down (APD) feature which
puts the IDEAA™ module in STANDBY if no input signal is detected for a period of 20 minutes. The Auto Power
On (APO) turns the module on in less than 2 seconds after a signal is present at the input.
MANUAL MODE – The power mode may be switched to MANUAL to disable the APD and APO functions.
This allows use of an external power sequencer or manual control. Because of the very low idle current
consumption, good overall ef฀ciency is maintained even when the MANUAL mode is selected.
4.3. Cooling
Do not install this equipment in an enclosed space. Do not limit free ventilation and movement of air around the
back panel. Ensure that there is at least 100 mm (4”) of space around all sides of the product for ventilation. VXP
products do not have cooling fans; the highly ef฀cient switch mode power supply and proprietary Class D output
stage have less current draw and therefore require only the convection cooling provided by the rear panel heat sink.
4.4. LED Functions
Limit LED - When illuminated this indicates that the system is approaching clipping. An occasional ฀icker of the
red LED on the loudest peaks is acceptable. If this LED remains red for more than the duration of brief dynamic
peaks, or lights continuously then the system is being overdriven. If the red LED illuminates excessively:
• Reduce the input level (see interface panel)
• Reduce the output level of the mixer, or other source to the speaker.
Signal LED – The Green LED indicates that a useable signal is present at the input.
Power LED – StandBy - Red
Active - Green
Temp Prot. - Amber
4. Operation
10
VXP Series Oper
4.5. Audio Connections
The signal input & link cofollowing standard:SIGNAL XLR CONNECHot (+) Pin 2Cold (-) Pin 3Shield (GND) Pin 1In a standard balanced intreferenced to ground at oneliminate “ground loops” shields can act as radio anMultiple enclosures may bXLR input socket, and pa
4.6. Gain Structure
The VXP gain structure isMaximum speci฀ed SPL wpath to accommodate inpumaintain sonic integrity wthe input attenuator on the
5.7 Limiters
The limiters are carefully transients to pass; audibleThe limiting functions wilunits. If used irresponsiblyunits may also be damage
5. Equalisation
VXP Series Operation Manual rev 3.0.0
11
5. Equalisation
The VXP loudspeaker requires no equalisation or correction to overcome system limitations; equalisation
is necessary only to compensate for dif฀cult acoustic environments. Over-equalisation can reduce system
headroom and introduce phase distortion, resulting in degraded sound. If equalisation is required, it should
be applied gently and smoothly. Because VXP loudspeakers are point source and phase coherent designs,
excessive equalization usually proves detrimental to the overall sound quality.
When one loudspeaker is used in close proximity to another, comb ฀ltering effects can create coverage
problems. (Comb ฀ltering creates an uneven frequency response across the coverage area due to constructive
and destructive interference effects between the two sources.) Comb ฀ltering cannot be cured by equalization;
this should be addressed with proper arraying as discussed in the following section.
7. Dimensio
VXP Series Operation M
13
7. Dimensions
VV3[12[2 [7711[
7. Dimensions
14
VXP Series Operation Manual rev 3.0.0
VXP 8.2
VXP 12
280.0
[11.02"]
590.0
[23.23"]
145.0
[5.71"]
60° 60°
180.0
[7.09"]
370.0
[14.57"]
360.0
[14.17"]
180.0
[7.09"]
290.0
[11.42"]
190.0
[7.48"] 60° 40°
486.0
[19.13"]
180.0
[7.09"]
406.0
[15.98"]
7. Dimensions
VXP Series Operation Manual rev 3.0.0
15
VXP 12HP
VXP 12Q
370.0
[14.57"]
360.0
[14.17"]
180.0
[7.09"]
290.0
[11.42"]
190.0
[7.48"] 60° 40°
486.0
[19.13"]
180.0
[7.09"]
406.0
[15.98"]
370.0
[14.57"]
360.0
[14.17"]
180.0
[7.09"]
290.0
[11.42"]
190.0
[7.48"] 60° 40°
486.0
[19.13"]
180.0
[7.09"]
406.0
[15.98"]
7. Dimensions
16
VXP Series Operation Manual rev 3.0.0
780.0
[30.71"]
370.0
[14.57"]
190.0
[7.48"]
40.0
[1.57"]
155.0
[6.10"]
180.0
[7.09"]
40.0
[1.57"]
290.0
[11.42"]
180.0
[7.09"]
190.0
[7.48"] 60° 40°
258.0
[10.16"]
155.0
[6.10"]
590.0
[23.23"]
43.0
[1.69"]
180.0
[7.09"]
504.0
[19.84"]
180.0
[7.09"]
364.0
[14.33"]
450.0
[17.72"]
200.0
[7.87"]
420.0
[16.54"]
200.0
[7.87"]
VXP 12.2Q
VXP 15HP
8. Rigging and Safety Procedures
18
VXP Series Operation Manual rev 3.0.0
8. Rigging and Safety Procedures
The Tannoy Professional hardware covered in this guide has been designed to offer quick, simple, cost
effective and secure solutions for mounting speci฀c Tannoy Professional loudspeakers. This hardware has been
designed and manufactured with a high safety load factor for its speci฀c role. To ensure the safest possible use
of the hardware covered in this guide, it must be assembled in strict accordance with the instructions speci฀ed.
The information in these manuals relating to the assembly and the safe use of these accessories must be
understood and followed.
The installation of Tannoy Professional loudspeakers using the dedicated hardware should carried out only
by fully quali฀ed installers, in accordance with all the required safety codes and standards that are applied
at the place of installation. WARNING: As the legal requirements for ฀ying change from country to country,
please consult your local safety standards of฀ce before installing any product. We also recommend that you
thoroughly check any laws and bylaws prior to installation.
Tannoy Professional hardware has been designed for use with speci฀c Tannoy Professional loudspeakers,
and is not designed or intended for use with any other Tannoy Professional products, or any other devices.
Using Tannoy Professional hardware for any purpose other than that indicated in this guide is considered to
be improper use. Such use can be very dangerous: overloading, modifying, damaging, or assembling in a
manner other than that clearly stated in the manual Tannoy Professional hardware will compromise safety. The
component parts of any Tannoy Professional hardware device must only be assembled using the accessory
kits supplied and in strict compliance with the Operation Manual. The use of other accessories or non-
approved methods of assembly may result in an unsafe hardware system by reducing the load safety factor.
Welding, or any other method of permanently ฀xing hardware components together or to the integral ฀xing
points in the cabinet should never be used.
Whenever a Tannoy Professional loudspeaker is ฀xed to a surface using a Tannoy Professional hardware
device, the installer must ensure that the surface is capable of safely and securely supporting the load. The
hardware employed must be safely and securely attached both to the loudspeaker and also to the surface
in question, in accordance with the manual, using only the ฀xing holes provided as standard and covered in
the manual. Secure ฀xings to the building structure are vital. Seek help from architects, structural engineers
or other specialists if in any doubt. All loudspeakers ฀own in theatres, nightclubs, conference centres or
other places of work and entertainment must be provided with an independent, correctly rated and securely
attached secondary safety restraint in addition to the principal hardware device. This secondary safety restraint
must prevent the loudspeaker from dropping more than 150 mm (6”) should the principal hardware device fail.
9. Service Parts & Accessories
VXP Series Operation Manual rev 3.0.0
19
9. Service Parts & Accessories
Model
VXP 6
VXP 8
VXP 8.2
VXP 12
VXP 12HP
VXP 12Q
VXP 12.2Q
VXP 15HP
VXP 15Q
Dual driver
7900 0742
7900 1282
7900 1282
7900 1285
7900 1289
7900 1290
7900 1290
7900 1293
7900 1294
HF unit
7900 0683
—
—
—
—
—
—
—
—
Recone Kit
—
—
—
7900 0441
7900 0716
7900 0716
7900 0716
7900 0646
7900 0646
HF diaphragm
—
7900 1284
7900 1284
7900 1287
7900 1292
7900 1292
7900 1292
7900 1292
7900 1292
Bass driver
—
—
7900 1283
—
—
—
7900 1291
—
—
Amplifier
7900 1306
7900 1307
7900 1308
7900 1309
7900 1310
7900 1311
7900 1312
7900 1313
7900 1314
Input board
7900 1315
7900 1316
7900 1317
7900 1317
7900 1318
7900 1318
7900 1318
7900 1318
7900 1318
10. Technical Specications
22
VXP Series Operation Manual rev 3.0.0
Model VXP 8.2
Peformance
Frequency Response (-3 dB) 1 Full range mode 75 Hz - 35 kHz
Frequency Range (-10 dB) 1 Full range mode 60 Hz - 45 kHz
Frequency Response (-3 dB) 1 Hi-Pass mode 100 Hz - 35 kHz
Frequency Range (-10 dB) 1 Hi-Pass mode 80 Hz - 45 kHz
Dispersion (-6 dB) 90 degrees conical
Driver Complement 1 x 200 mm (8.00”) constant directivity Dual Concentric™, 1 x 200 mm (8.00”) bass driver
Crossover Passive 360 Hz and 1.5 kHz, with dynamic HF protection
Directivity Factor (Q) 8.1 averaged 1 kHz to 8 kHz
Directivity Index (DI) 9.2 dB averaged 1 kHz to 8 kHz
Rated Maximum SPL 2117 dB (average), 123 dB (peak)
Distortion
10% Full Power (8.94 V) 2nd Harmonic 3rd Harmonic
250 Hz 0.58% 0.34%
1 kHz 0.34% 0.69%
10 kHz 1.73% 0.15%
1% Full Power (2.83 V) 2nd Harmonic 3rd Harmonic
250 Hz 0.15% 0.15%
1 kHz 0.11% 0.37%
10 kHz 0.74% 0.22%
Construction
Enclosure 19.20 litre, 15 mm (0.62”) birch plywood, vented and internally braced.
Finish Textured black or white paint, with custom colours on request.
Powder coated perforated steel grille, Airnet cloth behind
Connectors 1 x female XLR (input), 1 male XLR (link), 1 x Neutrik Powercon
Controls & Indicators Level Control
Power LED (Blue)
Signal LED (Red/Green)
Limit/Protect LED (Red)
Full Range / HighPass Switch (110 Hz)
Power Mode Switch
Power Switch
Fittings 4 x M10 ฀ying inserts, 4 x M10 yoke bracket inserts (6 mm allen key),
2 x Integrip carrying handles,
Blanking plate for optional VTH pole mount
Dimensions 590 x 280 x 275 mm (HxWxD), 23.2 x 11.0 x 10.8” (HxWxD)
Net Weight 17.5 kg (38.6 lbs)
Shipped Weight 20.0 kg (44.1 lbs)
Electronics
Maximum signal input for clip Input attenuator at Maximum: +4.5 dBu
(Hard clip will occur at +14.5 dBu input signal)
Dynamic Range 106 dB
Ampli฀er ef฀ciency >90%
Damping Factor >400 ref 8 ohms at 1 kHz
Distortion <0.05% @ 1 kHz -3 dB output (22 kHz bandwidth)
Input Impedance 10 kohms unbalanced, 20 kohms balanced
Protection systems
Over Current Output current limiter, always active
Clip limiter Output voltage clip limiter, always active
Temperature Over temperature causes protective mute
Brownout Automatic protection & recovery
Mains Inrush current limiter
Indicators 1x Power LED, 1x signal LED, 1x Limit LED
(Power LED: Red = StandBy, Green = On, Amber = Temperature protection active)
Ampli฀er Type Inherently bridged, globally modulated, high performance single channel class D
PSU Speci฀cations
Input Connector Locking Neutrik Powercon
Voltage Selection Universal mains input
Type High ef฀ciency, regulated switch mode power supply
Ef฀ciency >85% typical
Input voltage 100 Vac-240 Vac +/- 10%, 50-60 Hz +/-10%
Mains fuse Internal
Fuse type 3,15AT
Other features Inrush current limiter
StandBy power consumtion <1 W
Idle power consumption <15 W
Maximum power consumtion 250 W
1. Average over state d bandwidth. Measured at 1 metre on axis.
2. Unweighted pink n oise input, measured at 1 metre in a n anechoic chamber
A full range of measurements, per formance data, and Ease™ Data can be downloaded from www.tannoy.com
Tannoy operates a policy of continuous r esearch and development. The introduction of new materials or ma nufacturing methods will al ways equal or exceed the publish ed speci฀cations,
which Tannoy reserves the right to alter without prior noti฀cation.
10. Technic
VXP Series Operation M
23
Model VXP 12Peformance
Frequency Response (-3 dB)
1
Full range mode 70 Hz - 25 kHzFrequency Range (-10 dB)
1
Full range mode 55 Hz - 38 kHzFrequency Response (-3 dB)
1
Hi-Pass mode 100 Hz - 25 kHzFrequency Range (-10 dB)
1
Hi-Pass mode 80 Hz - 38 kHzDispersion (-6 dB) 90 degrees conicalDriver Complement 1 x 305 mm (12.00”) constant directivity Dual Concentric™Crossover Passive 1 kHz with HF protectionDirectivity Factor (Q) 9.6 averaged 1 kHz to 8 kHzDirectivity Index (DI) 9.8 averaged 1 kHz to 8 kHzRated Maximum SPL
2
121 dB (average), 127 dB (peak)Distortion10% Full Power (12.65 V) 2nd Harmonic 3rd Harmonic250 Hz 0.52% 0.58%1 kHz 2.98% 0.63%10 kHz 3.58% 0.19%1% Full Power (4 V) 2nd Harmonic 3rd Harmonic250 Hz 0.10% 0.26%1 kHz 0.81% 0.58%10 kHz 1.18% 0.03%
Construction
Enclosure 36.4 litre, 15 mm (enclosure) and 18 mm (front) birch plywood, vented and internally bracFinish Textured black or white paint, with custom colours on request.Powder coated perforated steel grille, Airnet cloth behindConnectors 1 x female XLR (input), 1 male XLR (link), 1 x Neutrik PowerconControls & Indicators Level Control Power LED (Blue)Signal LED (R)Limit/Protect LED (Red)Full Range / HighPass Switch (110 Hz)Power Mode SwitchPower SwitchFittings 8 x M10 Flying inserts (portrait or landscape mounting), 8 x M10 yoke bracket inserts1 x Integrip carrying handles Blanking plate for optional VTH pole mountDimensions 486 x 370 x 360 mm (HxWxD), 19.1 x 14.6 x 14.1” (HxWxD)Net Weight 19.0 kg (41.9 lbs)Shipped Weight 21.5 kg (47.4 lbs)
Electronics
Maximum signal input for clip Input attenuator at Maximum: +4.5 dBu(Hard clip will occur at +14.5 dBu input signal)Dynamic Range 106 dBAmpli฀er ef฀ciency >90%Damping Factor >400 ref 8 ohms at 1 kHzDistortion <0.05% @ 1 kHz -3 dB output (22 kHz bandwidth)Input Impedance 10 kohms unbalanced, 20 kohms balanced
Protection systems
Over Current Output current limiter, always activeClip limiter Output voltage clip limiter, always activeTemperature Over temperature causes protective muteBrownout Automatic protection & recoveryMains Inrush current limiterIndicators 1x Power LED, 1x signal LED, 1x Limit LED(Power LED: Red = StandBy, Green = On, A = Temperature protection active)Ampli฀er Type Inherently bridged, globally modulated, high performance single channel class D
PSU Speci฀cations
Input Connector Locking Neutrik PowerconVoltage Selection Universal mains inputType High ef฀ciency, regulated switch mode power supplyEf฀ciency >85% typicalInput voltage 100 Vac-240 Vac +/- 10%, 50-60 Hz +/-10%Mains fuse InternalFuse type 3,15ATOther features Inrush current limiterStandBy power consumtion <1 WIdle power consumption <15 WMaximum power consumtion2 W
1.retddi.seenx2itnoeuaudrncohbrAlnfsenefrne,ae™tnwoerww.ny.mTanpaoioioeahdlmnercoetasnauntdlwqleduiepiao,wioevsitrttio฀t.
10. Technical Specications
24
VXP Series Operation Manual rev 3.0.0
Model VXP 12HP
Peformance
Frequency Response (-3 dB) 1 Full range mode 70 Hz - 25 kHz
Frequency Range (-10 dB) 1 Full range mode 60 Hz - 30 kHz
Frequency Response (-3 dB) 1 Hi-Pass mode 100 Hz - 25 kHz
Frequency Range (-10 dB) 1 Hi-Pass mode 80 Hz - 30 kHz
Dispersion (-6 dB) 75 degrees conical
Driver Complement 1 x 305 mm (12.00”) constant directivity PowerDual™
Crossover Passive 1 kHz
Directivity Factor (Q) 10.1 averaged 1 kHz to 10 kHz
Directivity Index (DI) 10.0 dB averaged 1 kHz to 10 kHz
Rated Maximum SPL 2123 dB (average), 129 dB (peak)
Distortion
10% Full Power (16.7 V) 2nd Harmonic 3rd Harmonic
250 Hz 0.239% 0.67%
1 kHz 1.58% 3.54%
10 kHz 5.2% 0.19%
1% Full Power (5.29 V) 2nd Harmonic 3rd Harmonic
250 Hz 0.11% 0.581%
1 kHz 0.79% 2.53%
10 kHz 1.94% 0.161%
Construction
Enclosure 30.33 litre, 15 mm (enclosure) and 18 mm (front) birch plywood, vented and internally braced.
Finish Textured black or white paint, with custom colours on request.
Powder coated perforated steel grille, Airnet cloth behind
Connectors 1 x female XLR (input), 1 male XLR (link), 1 x Neutrik Powercon
Controls & Indicators Level Control
Power LED (Blue)
Signal LED (Red/Green)
Limit/Protect LED (Red)
Full Range / HighPass Switch (110 Hz)
Power Mode Switch
Power Switch
Fittings 8 x M10 Flying inserts (portrait or landscape mounting), 8 x M10 yoke bracket inserts
1 x Integrip carrying handles
Blanking plate for optional VTH pole mount
Dimensions 486 x 370 x 360 mm (HxWxD), 19.1 x 14.6 x 14.1” (HxWxD)
Net Weight 23.5 kg (51.8 lbs)
Shipped Weight 26.0 kg (57.3 lbs)
Electronics
Maximum signal input for clip Input attenuator at Maximum: +4.5 dBu
(Hard clip will occur at +14.5 dBu input signal)
Dynamic Range 106 dB
Ampli฀er ef฀ciency >90%
Damping Factor >400 ref 8 ohms at 1 kHz
Distortion <0.05% @ 1 kHz -3 dB output (22 kHz bandwidth)
Input Impedance 10 kohms unbalanced, 20 kohms balanced
Protection systems
Over Current Output current limiter, always active
Clip limiter Output voltage clip limiter, always active
Temperature Over temperature causes protective mute
Brownout Automatic protection & recovery
Mains Inrush current limiter
Indicators 1x Power LED, 1x signal LED, 1x Limit LED
(Power LED: Red = StandBy, Green = On, Amber = Temperature protection active)
Ampli฀er Type Inherently bridged, globally modulated, high performance single channel class D
PSU Speci฀cations
Input Connector Locking Neutrik Powercon
Voltage Selection Universal mains input
Type High ef฀ciency, regulated switch mode power supply
Ef฀ciency >85% typical
Input voltage 100 Vac-240 Vac +/- 10%, 50-60 Hz +/-10%
Mains fuse Internal
Fuse type 3,15AT
Other features Inrush current limiter
StandBy power consumtion <1 W
Idle power consumption <15 W
Maximum power consumtion 250 W
1. Average over state d bandwidth. Measured at 1 metre on axis.
2. Unweighted pink n oise input, measured at 1 metre in a n anechoic chamber
A full range of measurements, per formance data, and Ease™ Data can be downloaded from www.tannoy.com
Tannoy operates a policy of continuous r esearch and development. The introduction of new materials or ma nufacturing methods will al ways equal or exceed the publish ed speci฀cations,
which Tannoy reserves the right to alter without prior noti฀cation.
10. Technical Specications
VXP Series Operation Manual rev 3.0.0
25
Model VXP 12Q
Peformance
Frequency Response (-3 dB) 1 Full range mode 70 Hz - 25 kHz
Frequency Range (-10 dB) 1 Full range mode 60 Hz - 30 kHz
Frequency Response (-3 dB) 1 Hi-Pass mode 100 Hz - 25 kHz
Frequency Range (-10 dB) 1 Hi-Pass mode 80 Hz - 30 kHz
Dispersion (-6 dB) 75 degrees (H) x 40 degrees (V)
Driver Complement 1 x 305 mm (12.00”) PowerDual™ with Q-Centric waveguide
Crossover Passive 1.5 kHz
Directivity Factor (Q) 13.0 averaged 1 kHz to 8 kHz
Directivity Index (DI) 11.1 dB averaged 1 kHz to 8 kHz
Rated Maximum SPL 2123 dB (average), 129 dB (peak)
Distortion
10% Full Power (16.7 V) 2nd Harmonic 3rd Harmonic
250 Hz 0.72% 0.17%
1 kHz 0.57% 0.76%
10 kHz 5.11% 0.41%
1% Full Power (5.30 V) 2nd Harmonic 3rd Harmonic
250 Hz 0.16% 0.19%
1 kHz 0.18% 0.49%
10 kHz 1.63% 0.08%
Construction
Enclosure 36.4 litre, 15 mm (enclosure) and 18 mm (front) birch plywood, vented and internally braced.
Finish Textured black or white paint, with custom colours on request.
Powder coated perforated steel grille, Airnet cloth behind
Connectors 1 x female XLR (input), 1 male XLR (link), 1 x Neutrik Powercon
Controls & Indicators Level Control
Power LED (Blue)
Signal LED (Red/Green)
Limit/Protect LED (Red)
Full Range / HighPass Switch (110 Hz)
Power Mode Switch
Power Switch
Fittings 8 x M10 Flying inserts (portrait or landscape mounting), 8 x M10 yoke bracket inserts
1 x Integrip carrying handles
Blanking plate for optional VTH pole mount
Dimensions 486 x 370 x 360 mm (HxWxD), 19.1 x 14.6 x 14.1” (HxWxD)
Net Weight 23.0 kg (50.7 lbs)
Shipped Weight 25.0 kg (55.1 lbs)
Electronics
Maximum signal input for clip Input attenuator at Maximum: +4.5 dBu
(Hard clip will occur at +14.5 dBu input signal)
Dynamic Range 106 dB
Ampli฀er ef฀ciency >90%
Damping Factor >400 ref 8 ohms at 1 kHz
Distortion <0.05% @ 1 kHz -3 dB output (22 kHz bandwidth)
Input Impedance 10 kohms unbalanced, 20 kohms balanced
Protection systems
Over Current Output current limiter, always active
Clip limiter Output voltage clip limiter, always active
Temperature Over temperature causes protective mute
Brownout Automatic protection & recovery
Mains Inrush current limiter
Indicators 1x Power LED, 1x signal LED, 1x Limit LED
(Power LED: Red = StandBy, Green = On, Amber = Temperature protection active)
Ampli฀er Type Inherently bridged, globally modulated, high performance single channel class D
PSU Speci฀cations
Input Connector Locking Neutrik Powercon
Voltage Selection Universal mains input
Type High ef฀ciency, regulated switch mode power supply
Ef฀ciency >85% typical
Input voltage 100 Vac-240 Vac +/- 10%, 50-60 Hz +/-10%
Mains fuse Internal
Fuse type 3,15AT
Other features Inrush current limiter
StandBy power consumtion <1 W
Idle power consumption <15 W
Maximum power consumtion 250 W
1. Average over state d bandwidth. Measured at 1 metre on axis.
2. Unweighted pink n oise input, measured at 1 metre in a n anechoic chamber
A full range of measurements, per formance data, and Ease™ Data can be downloaded from www.tannoy.com
Tannoy operates a policy of continuous r esearch and development. The introduction of new materials or ma nufacturing methods will al ways equal or exceed the publish ed speci฀cations,
which Tannoy reserves the right to alter without prior noti฀cation.
10. Technical Specications
26
VXP Series Operation Manual rev 3.0.0
Model VXP 12.2Q
Peformance
Frequency Response (-3 dB) 1 Full range mode 60 Hz - 25 kHz
Frequency Range (-10 dB) 1 Full range mode 47 Hz - 30 kHz
Frequency Response (-3 dB) 1 Hi-Pass mode 100 Hz - 25 kHz
Frequency Range (-10 dB) 1 Hi-Pass mode 80 Hz - 30 kHz
Dispersion (-6 dB) 75 degrees (H) x 40 degrees (V)
Driver Complement 1 x 305 mm (12.00”) PowerDual™ with Q-Centric waveguide, 1 x 305 mm (12.00”) bass driver
Crossover Passive 300 Hz and 1.5 kHz
Directivity Factor (Q) 13.0 averaged 1 kHz to 8 kHz
Directivity Index (DI) 11.1 dB averaged 1 kHz to 8 kHz
Rated Maximum SPL 2125 dB (average), 131 dB (peak)
Distortion
10% Full Power (20.0 V) 2nd Harmonic 3rd Harmonic
250 Hz 2.49% 0.49%
1 kHz 0.54% 0.73%
10 kHz 7.54% 0.80%
1% Full Power (6.33 V) 2nd Harmonic 3rd Harmonic
250 Hz 0.60% 0.21%
1 kHz 0.20% 0.49%
10 kHz 2.56% 0.10%
Construction
Enclosure 53.33 litre, 15 mm (enclosure) and 18 mm (front) birch plywood, vented and internally braced.
Finish Textured black or white paint, with custom colours on request.
Powder coated perforated steel grille, Airnet cloth behind
Connectors 1 x female XLR (input), 1 male XLR (link), 1 x Neutrik Powercon
Controls & Indicators Level Control
Power LED (Blue)
Signal LED (Red/Green)
Limit/Protect LED (Red)
Full Range / HighPass Switch (110 Hz)
Power Mode Switch
Power Switch
Fittings 8 x M10 corner ฀ying inserts, 8 x M10 yoke bracket inserts
2 x Integrip carrying handles
Blanking plate for optional VTH pole mount
Dimensions 780 x 370 x 360 mm (HxWxD), 30.7 x 14.6 x 14.1” (HxWxD)
Net Weight 35.0 kg (77.2 lbs)
Shipped Weight 38.0 kg (83.8 lbs)
Electronics
Maximum signal input for clip Input attenuator at Maximum: +4.5 dBu
(Hard clip will occur at +14.5 dBu input signal)
Dynamic Range 106 dB
Ampli฀er ef฀ciency >90%
Damping Factor >400 ref 8 ohms at 1 kHz
Distortion <0.05% @ 1 kHz -3 dB output (22 kHz bandwidth)
Input Impedance 10 kohms unbalanced, 20 kohms balanced
Protection systems
Over Current Output current limiter, always active
Clip limiter Output voltage clip limiter, always active
Temperature Over temperature causes protective mute
Brownout Automatic protection & recovery
Mains Inrush current limiter
Indicators 1x Power LED, 1x signal LED, 1x Limit LED
(Power LED: Red = StandBy, Green = On, Amber = Temperature protection active)
Ampli฀er Type Inherently bridged, globally modulated, high performance single channel class D
PSU Speci฀cations
Input Connector Locking Neutrik Powercon
Voltage Selection Universal mains input
Type High ef฀ciency, regulated switch mode power supply
Ef฀ciency >85% typical
Input voltage 100 Vac-240 Vac +/- 10%, 50-60 Hz +/-10%
Mains fuse Internal
Fuse type 3,15AT
Other features Inrush current limiter
StandBy power consumtion <1 W
Idle power consumption <15 W
Maximum power consumtion 250 W
1. Average over state d bandwidth. Measured at 1 metre on axis.
2. Unweighted pink n oise input, measured at 1 metre in a n anechoic chamber
A full range of measurements, per formance data, and Ease™ Data can be downloaded from www.tannoy.com
Tannoy operates a policy of continuous r esearch and development. The introduction of new materials or ma nufacturing methods will al ways equal or exceed the publish ed speci฀cations,
which Tannoy reserves the right to alter without prior noti฀cation.
10. Technical Specications
VXP Series Operation Manual rev 3.0.0
27
1. Average over stated bandwidth. Measured at 1 metre on axis.
2. Unweighted pink noise input, measured at 1 metre in an anechoic chamber
A full range of measurements, performance data, and Ease™ Data can be downloaded from www.tannoy.com
Tannoy operates a policy of continuous research and development. The introduction of new materials or manufacturing methods will always equal or exceed the published speci฀cations,
which Tannoy reserves the right to alter without prior noti฀cation
Model VXP 15HP
Peformance
Frequency Response (-3 dB) 1 Full range mode 60 Hz - 25 kHz
Frequency Range (-10 dB) 1 Full range mode 47 Hz - 30 kHz
Frequency Response (-3 dB) 1 Hi-Pass mode 100 Hz - 25 kHz
Frequency Range (-10 dB) 1 Hi-Pass mode 80 Hz - 30 kHz
Dispersion (-6 dB) 75 degrees conical
Driver Complement 1 x 380 mm (15.00”) constant directivity PowerDual™
Crossover Passive 1.3 kHz
Directivity Factor (Q) 9.7 averaged 1 kHz to 8 kHz
Directivity Index (DI) 9.9 dB averaged 1 kHz to 8 kHz
Rated Maximum SPL 2125 dB (average), 131 dB (peak)
Distortion
10% Full Power (17.9 V) 2nd Harmonic 3rd Harmonic
250 Hz 1.0% 0.56%
1 kHz 1.4% 1.0%
10 kHz 3.9% 1.8%
1% Full Power (5.6 V) 2nd Harmonic 3rd Harmonic
250 Hz 0.31% 0.45%
1 kHz 0.45% 0.79%
10 kHz 3.16% 0.32%
Construction
Enclosure 52.96 litre, 18 mm birch plywood, vented and internally braced.
Finish Textured black or white paint, with custom colours on request.
Powder coated perforated steel grille, Airnet cloth behind
Connectors 1 x female XLR (input), 1 male XLR (link), 1 x Neutrik Powercon
Controls & Indicators Level Control
Power LED (Blue)
Signal LED (Red/Green)
Limit/Protect LED (Red)
Full Range / HighPass Switch (110 Hz)
Power Mode Switch
Power Switch
Fittings 8 x M10 corner ฀ying inserts, 8 x M10 yoke bracket inserts
1 x Integrip carrying handles
Blanking plate for optional VTH pole mount
Dimensions 590 x 450 x 420 mm (HxWxD), 23.2 x 17.7 x 16.5” (HxWxD)
Net Weight 29.0 kg (63.9 lbs)
Shipped Weight 31.5 kg (69.4 lbs)
Electronics
Maximum signal input for clip Input attenuator at Maximum: +4.5 dBu
(Hard clip will occur at +14.5 dBu input signal)
Dynamic Range 106 dB
Ampli฀er ef฀ciency >90%
Damping Factor >400 ref 8 ohms at 1 kHz
Distortion <0.05% @ 1 kHz -3 dB output (22 kHz bandwidth)
Input Impedance 10 kohms unbalanced, 20 kohms balanced
Protection systems
Over Current Output current limiter, always active
Clip limiter Output voltage clip limiter, always active
Temperature Over temperature causes protective mute
Brownout Automatic protection & recovery
Mains Inrush current limiter
Indicators 1x Power LED, 1x signal LED, 1x Limit LED
(Power LED: Red = StandBy, Green = On, Amber = Temperature protection active)
Ampli฀er Type Inherently bridged, globally modulated, high performance single channel class D
PSU Speci฀cations
Input Connector Locking Neutrik Powercon
Voltage Selection Universal mains input
Type High ef฀ciency, regulated switch mode power supply
Ef฀ciency >85% typical
Input voltage 100 Vac-240 Vac +/- 10%, 50-60 Hz +/-10%
Mains fuse Internal
Fuse type 3,15AT
Other features Inrush current limiter
StandBy power consumtion <1 W
Idle power consumption <15 W
Maximum power consumtion 250 W
11. Warranty
VXP Series Operation Manual rev 3.0.0
29
11. Warranty
No maintenance of the VXP Series loudspeakers is necessary.
As part of the MUSIC Group, Tannoy is committed to providing the highest quality products, service and
user experience for our customers. One element of this commitment is our after sales support which now
incorporates our extended Limited Warranty. In the event of any concern that is not addressed by this extended
Limited Warranty we would ask you to contact us at care@music-group.com
For full warranty details including the extended Limited Warranty, please visit
http://www.music-group.com/warranty.aspx and register your purchase online at www.music-group.com
or www.tannoy.com

Tuotetiedot

Merkki: Tannoy
Kategoria: Kaiutin
Malli: VXP 12Q

Tarvitsetko apua?

Jos tarvitset apua merkille Tannoy VXP 12Q esitä kysymys alla ja muut käyttäjät vastaavat sinulle


Kaiutin Tannoy Käyttöohjeet

Tannoy

Tannoy VXP 12.2Q Käyttöohje

22 Tammikuuta 2025
Tannoy

Tannoy VXP 12Q Käyttöohje

22 Tammikuuta 2025
Tannoy

Tannoy VXP 12HP Käyttöohje

22 Tammikuuta 2025
Tannoy

Tannoy VXP 15Q Käyttöohje

22 Tammikuuta 2025
Tannoy

Tannoy QFLEX 24 Käyttöohje

1 Tammikuuta 2025
Tannoy

Tannoy QFLEX 32 Käyttöohje

1 Tammikuuta 2025
Tannoy

Tannoy AUTOGRAPH MINI-OW Käyttöohje

1 Tammikuuta 2025
Tannoy

Tannoy ARCO GRILLE CMS 603-WH Käyttöohje

1 Tammikuuta 2025
Tannoy

Tannoy VMS 1 Käyttöohje

28 Joulukuuta 2024
Tannoy

Tannoy QCI 3 Käyttöohje

28 Joulukuuta 2024

Kaiutin Käyttöohjeet

Viimeisimmät Kaiutin Käyttöohjeet

LD Systems

LD Systems STINGER G3 TMB Käyttöohje

8 Huhtikuuta 2025
JBL

JBL Conceal C83 Käyttöohje

8 Huhtikuuta 2025
JBL

JBL Control 426LP Käyttöohje

8 Huhtikuuta 2025
Crestron

Crestron SAROS ICE4T Käyttöohje

7 Huhtikuuta 2025
Crestron

Crestron SAROS ICI6T Käyttöohje

7 Huhtikuuta 2025
Crestron

Crestron SAROS IC8T Käyttöohje

7 Huhtikuuta 2025
Focal

Focal K2 Power M FRAK Käyttöohje

5 Huhtikuuta 2025
Turbosound

Turbosound PQ12-SB Käyttöohje

3 Huhtikuuta 2025
Trust

Trust Tytan GXT 658 Käyttöohje

3 Huhtikuuta 2025
Turbosound

Turbosound PQ15-YB Käyttöohje

3 Huhtikuuta 2025
