I N S T A L L A T I O N I N S T R U C T I O N S
RSA Projector Mounts
RPA Elite Series Projector Mount
RPA Elite Series Projector Mount
RPA Elite Series Projector Mount
RPA Elite Series Projector Mount
RPA Elite Series Projector Mount
RPA Elite Series Projector Mount
RSA
RSA Projector Mounts Installation Instructions
2
DISCLAIMER
Milestone AV Technologies, and its affiliated corporations and
subsidiaries (collectively, "Milestone"), intend to make this
manual accurate and complete. However, Milestone makes no
claim that the information contained herein covers all details,
conditions or variations, nor does it provide for every possible
contingency in connection with the installation or use of this
product. The information contained in this document is subject
to change without notice or obligation of any kind. Milestone
makes no representation of warranty, expressed or implied,
regarding the information contained herein. Milestone assumes
no responsibility for accuracy, completeness or sufficiency of
the information contained in this document.
Chief® is a registered trademark of Milestone AV Technologies.
All rights reserved.
IMPORTANT SAFETY INSTRUCTIONS!
WARNING: A WARNING alerts you to the possibility of
serious injury or death if you do not follow the instructions.
CAUTION: A CAUTION alerts you to the possibility of
damage or destruction of equipment if you do not follow the
corresponding instructions.
WARNING: Failure to read, thoroughly understand, and
follow all instructions can result in serious personal injury,
damage to equipment, or voiding of factory warranty! It is the
installer’s responsibility to make sure all components are
properly assembled and installed using the instructions
provided.
WARNING: Failure to provide adequate structural strength
for this component can result in serious personal injury or
damage to equipment! It is the installer’s responsibility to
make sure the structure to which this component is attached
can support five times the combined weight of all equipment.
Reinforce the structure as required before installing the
component.
WARNING: Exceeding the weight capacity can result in
serious personal injury or damage to equipment! It is the
installer’s responsibility to make sure the combined weight of
all components attached to the RSA does not exceed 25 lbs
(11.37 kg).
• The weight capacity of the RSA may be LIMITED to the
lowest weight capacity of any other components
located between the RSA and the supporting structure!
WARNING: Use this mounting system only for its intended
use as described in these instructions. Do not use
attachments not recommended by the manufacturer.
WARNING: Never operate this mounting system if it is
damaged. Return the mounting system to a service center for
examination and repair.
WARNING: Do not use this product outdoors.
IMPORTANT ! : The RSA mounts are designed to be:
• mounted to a 1-1/2" NPT or NPSM following ANSI/
ASME B1.20.1 (Schedule 40, 0.154" minimum
thickness aluminum - ASTM B221) threaded extension
column;
• mounted to double 2" x 4" wood stud cross bracing
(1-1/2" on center) between two 2" x 4" ceiling joists;
• mounted to a concrete ceiling with a minimum
thickness of 8" and a maximum drywall covering of
5/8"; or
• suspended from four 1/4" diameter (minimum) Grade 2
or better threaded rods (not included) which are
secured to unistrut, angle or channel assembly
overhead structural members (trusses or I-beams) by
Grade 2 or better 1/4" channel nuts (not included).
--SAVE THESE INSTRUCTIONS--
DIMENSIONS
4.39
111.6
4°
ROLL ADJUSTMENT
4.38
111.1
2.88
BOLT CIRCLE
73
.22
5.6
THREADS ONTO 1-1/2' NPT
1.44
36.5
25°
PITCH ADJUSTMENT
3.10
78.8
Installation Instructions RSA Projector Mounts
3
LEGEND
Tighten Fastener
Serrez les fixations
Serrare il fissaggio
Befestigungsteil festziehen
Apretar elemento de fijación
Bevestiging vastdraaien
Apertar fixador
Loosen Fastener
Desserrez les fixations
Allentare il fissaggio
Befestigungsteil lösen
Aflojar elemento de fijación
Bevestiging losdraaien
Desapertar fixador
Phillips Screwdriver
Tournevis à pointe cruciforme
Cacciavite a stella
Kreuzschlitzschraubendreher
Destornillador Phillips
Kruiskopschroevendraaier
Chave de fendas Phillips
Hex-Head Wrench
Clé à tête hexagonale
Chiave esagonale
Sechskantschlüssel
Llave de cabeza hexagonal
Zeskantsleutel
Chave de cabeça sextavada
Open-Ended Wrench
Clé à fourche
Chiave a punte aperte
Gabelschlüssel
Llave de boca
Steeksleutel
Chave de bocas
By Hand
À la main
A mano
Von Hand
A mano
Met de hand
Com a mão
Pencil Mark
Marquage au crayon
Segno a matita
Stiftmarkierung
Marcar con lápiz
Potloodmerkteken
Marcar com lápis
Drill Hole
Percez un trou
Praticare un foro
Bohrloch
Perforar
Gat boren
Fazer furo
Adjust
Ajuster
Regolare
Einstellen
Ajustar
Afstellen
Ajustar
Remove
Retirez
Rimuovere
Entfernen
Quitar
Verwijderen
Remover
Optional
En option
Opzionale
Optional
Opcional
Optie
Opcional
Security Wrench
Clé de sécurité
Chiave di sicurezza
Sicherheitsschlüssel
Llave de seguridad
Veiligheidssleutel
Chave de segurança
