701 S. RIDGE AVENUE
TROY, OHIO 45374-0001
937 332-3000
www.hobartcorp.com FORM 16556 Rev. A (August 2017)
MODEL 84145 FOOD CUTTER
ML-33221
– 2 –
© HOBART, 2017
Installation, Operation and Care of
MODEL 84145 FOOD CUTTER
SAVE THESE INSTRUCTIONS
GENERAL
The Model 84145 Food Cutter is designed to cut and mix a
wide variety of products. With products in the rotating 14"
(355mm) stainless steel bowl, rotating knives cut and mix
them inside the bowl cover. The food cutter is powered by
a 1/2 horsepower motor and is available for single- or three-
phase electrical service.
The Model 84145 is furnished with a #12 attachment hub.
Various attachments for this model, available through Hobart,
include: #12 Meat and Food Chopper; #12 Vegetable Slicer;
#12 Dicer/French Fry Cutter; and #12 Speed Drive (for use
with #12 Vegetable Slicer only).
INSTALLATION
UNPACKING
The food cutter was inspected before leaving the factory. The carrier assumes full responsibility for the safe
delivery upon acceptance of the shipment. Check for possible shipping damage immediately after receipt.
If the food cutter is found to be damaged, complete the following steps:
 1.Carriermustbenotiedwithinvebusinessdaysofreceipt.
 2.Carrier'slocalterminalmustbenotiedimmediatelyupondiscovery(notetime,date,andwhowas
spokento),andfollowupandconrmwithwrittenorelectroniccommunication.
3. All original packing materials must be kept for inspection purposes.
 4.Thefoodcuttercannothavebeenmoved,installed,ormodied.
5. Notify Hobart customer care at (800) 333-7447.
Priortoinstallation,testtheelectricalservicetoassurethatitagreeswiththespecicationsonthemachine
dataplate.Itisimportanttocheckknifeclearancebeforeturningonthemachineforthersttime.Ifthe
knife touches the bowl or bowl cover, contact your local Hobart Servicer.
LOCATION
With the legs installed, place the machine on a sturdy level surface.
ELECTRICAL CONNECTIONS
The supply cord on this machine is provided with a three-prong or four-prong
grounding plug. It is imperative that this plug be connected to a properly grounded, mating
receptacle. If the receptacle is not the proper grounding type, an electrician should be contacted.
– 3 –
CLEANING
This machine must be cleaned after installation and before being put into service. Refer to CLEANING
for instructions.
OPERATION
SAFETY
Safety devices incorporated in this machine must be in their correct operating
position anytime the food cutter is in use.
The HAND KNOB (Fig. 1) must be tightened snugly
against the knife unit.
The COMB must be positioned on the locking adapter
as shown in Fig. 1.
The BOWL COVER (Fig. 2) must be closed over the
bowl and securely locked by pressing down on the
locking handle and turning it 90°.
The START-STOP switch (Fig. 2), which controls
power to the food cutter, is mechanically interlocked
with the BOWL COVER. The switch cannot be pulled
to the ON position unless the bowl cover is locked in
place. With the switch in the ON position, the bowl
cover cannot be unlocked.
Always UNPLUG the power cord before cleaning or moving the food cutter.
OPERATION
Start the machine by pulling the START-
STOP switch (Fig. 2). Gradually feed the
product directly into the bowl as it rotates.
The bowl cover is shaped to turn and mix
products as the bowl rotates.
Hands must never be
inserted under the bowl cover during
operation of the machine, as sharp
rotating knives are located under the
bowl cover.
If additional mixing is desired, use a spatula
(or similar utensil) to turn the product as it
rotates past the bowl opening.
To unload the bowl, use a spatula to scrape
the product into a bowl or pan from the bowl
opening. This may be done while the bowl
rotates or you may turn the machine on and
o󰀨torotatetheproducttothebowlopening.
Fig. 1
Fig. 2
