IMPORTANT SAFETY
INSTRUCTIONS
READ AND SAVE THESE SAFETY
INSTRUCTIONS BEFORE USING
THIS FAN
When using electrical appliances, basic
precautions should always be followed to
reduce the risk of fire, electric shock, and
injury to persons, including the following:
FOR US MODELS ONLY - This product
employs overload protection (fuse). A
blown fuse indicates an overload or short-
circuit situation. If the fuse blows, unplug
the product from the outlet. Replace the
fuse as per the user servicing instructions
(follow product marking for proper fuse
rating) and check the product. If the
replacement fuse blows, a short-circuit
may be present and the product should
be discarded or returned to an authorized
service facility for examination and/or
repair.
1. Use this fan only as described in this
manual. Other use not recommended as it
may cause fire, electric shock or injury to
persons.
2. This product is intended for household
use and not for commercial, ONLY
industrial or outdoor use.
3. To protect against electric shock, do not
place fan in window, immerse unit, plug
or cord in water or spray with liquids.
4. This appliance has a polarized plug
(one blade is wider than the other). To
reduce the risk of shock, this plug is
intended to fit only one way in a polarized
outlet. If the plug does not fit fully in the
outlet, reverse the plug. If it still does
not fit, contact a qualified electrician.
DO NOT attempt to defeat this safety
feature.
5. Close supervision is necessary when any
appliance is used by or near children.
6. Turn the fan OFF and unplug the fan from
the outlet when not in use, when moving
the fan from one location to another and
before cleaning.
7. To disconnect the fan, first turn the unit
OFF, grip the plug and pull it from the
wall outlet. Never pull the plug by the
cord.
8. Do not operate the fan in the presence of
explosive and/or flammable fumes.
9. Do not place the fan or any parts near
an open flame, cooking or other heating
appliance.
10. Do not operate the fan with a
damaged cord or plug or if the product
malfunctions, is dropped
or damaged in any manner
(see warranty).
11. Avoid contact with moving fan parts.
12. The use of attachments not recommended
by the manufacturer may be hazardous.
13. Place the fan on a dry level surface.
14. Do not hang or mount fan on a wall
or ceiling.
15. Do not operate if the fan housing is
damaged.
16. A loose fit between the AC outlet
(receptacle) and plug may cause
overheating and a distortion of the plug.
Contact a qualified electrician to replace
loose or worn outlet.
QUIETSET™
WHOLE ROOM STAND FAN
HS-1650 Series
HS-1660 Series
Owner’s Manual
The Honeywell trademark is used by Kaz USA, Inc. under license from Honeywell International Inc.
Honeywell International Inc. makes no representation or warranties with respect to this product.
2
Fig. 1
Fig. 2
Fig. 3
FUSED SAFETY PLUG - FOR US MODELS ONLY
USER SERVICING INSTRUCTIONS
1. Grasp plug and remove from the receptacle or other outlet device. Do
not unplug by pulling on cord.
2. If your fan loses power and you suspect that the fuse on your fan has
blown, you should first remove the spare fuse holder attached to the
cord plug (Fig. 1). Remove the spare fuse from the plastic spare fuse
holder, and set the spare fuse aside (Fig. 2).
3. You can gain access to the blown fuse by sliding open the door found
on the side of the plug. Slide the door outward until the blown fuse is
fully visible (Fig. 3).
4. Carefully remove the blown fuse and snap the replacement fuse into
place. Risk of fire. Replace fuse only with 2.5 Amp, 125 volt fuse
(provided with product). Fully close the fuse door by sliding back into
place. Discard the blown fuse. The plug should now be ready for
normal use.
5. Risk of fire. Do not replace attachment plug. Contains a safety
device (fuse) that should not be removed. Discard product if the
attachement plug is damaged.
6. If you need further information on how or when to replace the fuse in
the safety plug, please contact Kaz Consumer Relations Department by
visiting our website at www.kaz.com or calling 1-800-477-0457.
This fan features a fused safety plug which is designed to cut off electric current to the fan if an
electrical fault occurs. Please see below for more information on how to properly use your fan and
replace the safety plug fuse, if needed.
17. Do not operate any fan with a damaged
cord or plug. Discard any damaged fan,
return the fan to the retailer where the
fan was purchased, or request a return
authorization to return to Kaz, Inc. for
examination and/or repair.
18. Do not run fan cord under carpeting. Do
not cover cord with throw rugs, runners,
or similar coverings. Do not route cord
under furniture or appliances. Arrange
cord away from traffic areas and where it
will not be tripped over.
WARNING: To Reduce The Risk of Fire
or Electric Shock, Do Not Use This Fan With
Any Solid State Speed Conrol Device
3
ASSEMBLY INSTRUCTIONS
Clips (G)
Blade Knob (D)
Front Grille
Fan Blade
Control
Panel
Rear Grille
Mounting
Nut (E) Rear Grille (F)
Motor
Assembly (C)
Height Adjustment
Knob (B)
Metal Fan Pole (A)
Base
A. Base Assembly
• Place base on a flat surface
• Fit bottom of Metal Fan Pole (A) into circular recess in fan base (Fig.2).
B. Securing the Fan Pole to the Base
• Align 3 screw holes at the base of Metal Fan Pole (A) with the 3 holes at the base.
• Secure the Metal Fan Pole to the base by inserting and tightening the 3 screws in
the 3 holes on the bottom of the base (Fig. 2).
• Slide the Pole Base Cover into place in the base and turn COUNTER-CLOCKWISE
until it snaps securely into place.
C. Determining the Height of the Fan
• Turn the Height Adjustment Knob (B) in a COUNTER-CLOCKWISE direction so that
the Knob loosens around the Metal Pole Extension.
• Pull the Metal Pole Extension out of the Metal Fan Pole to the desired height.
• Turn the Height Adjustment Knob (B) in a CLOCKWISE direction to tighten and
secure the Metal Pole Extension into place at the desired height.
Fig. 1 Metal
Pole
A
Metal
Fan
Pole
Fig. 2
Screws
A
Metal
Fan
Pole
Pole Base Cover
B
Height
Adjustment
Knob
Metal Fan Pole (A)
