Sivu 1/24
1
IMPORTANT SAFETY
INSTRUCTIONS
READ AND SAVE THESE SAFETY
INSTRUCTIONS BEFORE USING
THIS FAN
When using electrical appliances,
basic precautions should always
be followed to reduce the risk of
fire, electric shock, and injury to
persons, including the following:
FOR US MODELS ONLY – This product
employs overload protection (fuse). A blown
fuse indicates an overload or short-circuit
situation. If the fuse blows, unplug the product
from the outlet. Replace the fuse as per the
user servicing instructions (follow product
marking for proper fuse rating) and check
the product. If the replacement fuse blows,
a short-circuit may be present and the
product should be discarded or returned to an
authorized service facility for examination and/
or repair.
1. Use this fan only as described in this
manual. Other use not recommended as
it may cause fire, electric shock or injury
to persons.
2. This product is intended for household
use ONLY and not for commercial,
industrial or outdoor use.
3. To protect against electric shock, do not
place fan in window, immerse unit, plug
or cord in water or spray with liquids.
4. This appliance has a polarized plug
(one blade is wider than the other). To
reduce the risk of shock, this plug is
intended to fit only one way in a polarized
outlet. If the plug does not fit fully in the
outlet, reverse the plug. If it still does
not fit, contact a qualified electrician.
DO NOT attempt to defeat this safety
feature.
5. Close supervision is necessary when any
appliance is used by or near children.
6. Turn the fan and unplug the fan from OFF
the outlet when not in use, when moving
the fan from one location to another and
before cleaning.
7. To disconnect the fan, first turn the unit
OFF, grip the plug and pull it from the wall
outlet. Never pull the plug by the cord.
8. Do not operate the fan in the presence of
explosive and/or flammable fumes.
9. Do not place the fan or any parts near
an open flame, cooking or other heating
appliance.
10. Do not operate the fan with a
damaged cord or plug or if the product
malfunctions, is dropped
or damaged in any manner
(see warranty).
11. Avoid contact with moving fan parts.
12. The use of attachments not
recommended by the manufacturer may
be hazardous.
13. Place the fan on a dry level surface.
14. Do not hang or mount fan on a wall
or ceiling.
15. Do not operate if the fan housing is
damaged.
QUIETSET®
WHOLE ROOM TOWER FAN
HY-254 Series
HY-280 Series
Owner’s Manual
The Honeywell Trademark is used by Kaz USA, Inc. under license from Honeywell International Inc.
Honeywell International Inc. makes no representation or warranties with respect to this product.
2
16. A loose fit between the AC outlet
(receptacle) and plug may cause
overheating and a distortion of the plug.
Contact a qualified electrician to replace
loose or worn outlet.
17. Do not operate any fan with a damaged
cord or plug. Discard any damaged fan,
return the fan to the retailer where the
fan was purchased, or request a return
authorization to return to Kaz USA, Inc. for
examination and/or repair.
18. Do not run fan cord under carpeting. Do
not cover cord with throw rugs, runners,
or similar coverings. Do not route cord
under furniture or appliances. Arrange
cord away from traffic areas and where it
will not be tripped over.
WARNING: To Reduce The Risk of Fire or
Electric Shock, Do Not Use This Fan With
Any Solid-State Speed Control Device,
other than the one supplied.
USER SERVICING INSTRUCTIONS
• Grasp plug and remove from the receptacle or other outlet device.
Do not unplug by pulling on cord.
• If your fan loses power and you suspect that the fuse on your fan
has blown, you should first remove the spare fuse holder attached
to the cord plug (Fig. 1). Remove the spare fuse from the plastic
spare fuse holder, and set the spare fuse aside (Fig. 2).
• You can gain access to the blown fuse by sliding open the door
found on the side of the plug. Slide the door outward until the
blown fuse is fully visible (Fig. 3).
• Carefully remove the blown fuse and snap the replacement fuse
into place. Risk of fire. Replace fuse only with 2.5 Amp, 125 volt
fuse (provided with product). Fully close the fuse door by sliding
back into place. Discard the blown fuse. The plug should now be
ready for normal use.
• Risk of fire. Do not replace attached plug. Contains a safety device
(fuse) that should not be removed. Discard product if the attached
plug is damaged.
• If you need further information on how or when to replace the
fuse in the safety plug, please contact Kaz Consumer Relations
Department by visiting our website at www.kaz.com or calling
1-800-477-0457.
Thank you for your purchase.
This fan features a fused safety plug which is designed to cut off electric current to the fan if an
electrical fault occurs. Please see below for more information on how to properly use your fan and
replace the safety plug fuse, if needed.
FUSED SAFETY PLUG - FOR US ONLY
Fig. 1
Fig. 2
Fig. 3
3
A. Pedestal Assembly
• Line up the left and right pedestal assembly and firmly snap
together (Fig. 1).
B. Base Assembly
• Align the two portions of the circular base and snap together by
gently pushing the 4 extrusions (Fig. 2, Item A) into the adjacent
circles of the connecting piece (Fig. 2, Item B).
C. Securing the Pedestal to the Base
• Align the 3 screw holes on bottom of pedestal with the 3 holes
in the base such that the power cord holder is at the rear of the
unit . (Fig. 3)
• Secure the base assembly to the pedestal by inserting and
tightening the 3 screws in the 3 holes located on the bottom
of the base (Fig. 4).
D. Securing the Tower Fan to the Pedestal
• Carefully turn the fan on its side and place on a table. Place
the power cord through the center of the pedestal and base
assembly.
• Align the pedestal with the tower fan so that the one locking
screw hole on the pedestal body is aligned with the rear of
the tower fan unit. Firmly hold the base steady and rotate
the pedestal assembly clockwise to lock the tower fan to the
pedestal assembly (Fig. 5).
• Secure the pedestal to the tower fan by inserting and tightening
1 screw in the opening located near the top rear of the pedestal
assembly (Fig. 6).
E. Securing the Cord to the Base
• With the fan still on its side, locate the cord holding bracket on
the bottom of the base.
• Gently pull any slack out of the power cord, place the power
cord securely in the holding bracket and secure the power cord
bracket over the power cord (Fig. 7).
• Return the tower fan to its upright position.
Note: Do not operate the tower fan unless it is in its proper,
upright position.
ASSEMBLY INSTRUCTIONS
Fig. 1
Pedestal Assembly
Fig. 5
Fig. 7
Fig. 6
Fig. 4
A
B
Extrusions
Fig. 2
Base Assembly
Fig. 3
Positioning
Hole
Positioning
Pole
