SAFETY
INFORMATION
• Use the speaker in normal temperatures.
• Do not use the speaker under the water.
• Do not throw the speaker.
• Do not cover or insert anything into the
holes in the speaker.
• Do not put the speaker close to any heat
source.
• Contact your retailer if the charging cable
does not connect to your speaker.
• Do not disassemble, repair, or modify the
speaker.
• Do not charge the speaker using more
than 5V.
• High volumes may damage your hearing.
Use the speaker at a lower volume.
• Disassembling the speaker voids its
warranty.
PACKAGE CONTENTS
• Bluetooth Speaker
• Micro USB cable
• Quick Setup Guide
Before using your new product, please read
these instructions to prevent any damage.
FEATURES
Top
Side
Power button
Volume +/- buttons
Call
button
Bluetooth LED
CHARGING YOUR
SPEAKER
The charging LED blinks red when the
speaker’s battery is low.
• Connect the micro USB cable from your
speaker’s micro USB port to a USB port
(such as a computer or wall charger). The
charging LED lights red while charging,
then turns off when the battery is fully
charged.
CONNECTING AN
AUDIO DEVICE
Bluetooth
1 Press and hold (power) to turn on
your speaker. The Bluetooth LED blinks
blue quickly and your speaker
automatically enters pairing mode.
2 Make sure that your Bluetooth device is
within 33 ft. (10 m) of your speaker.
3 Turn on your Bluetooth device, turn on
Bluetooth, then enter pairing mode. For
more information, see the documenta-
tion that came with your Bluetooth
device.
Charging
LED
Reset hole
Micro USB
port
AUX IN
jack
4 On your Bluetooth device, select
NS-CSPBTF1. Your speaker pairs with
your Bluetooth device and the
Bluetooth LED lights solid blue.
5 To disconnect, un-pair your Bluetooth
device from your speaker.
Audio cable
• Connect a 3.5 mm audio cable (not
included) from your speaker’s AUX IN
jack to your audio device’s
headphone/audio out jack.
USING YOUR
SPEAKER
Listening to audio
1 Play audio on your connected device.
2 Press + or - to adjust your speaker’s
volume.
Note: Make sure that your connected
device’s volume is set to at least 50%.
3 Use the controls on your connected
device to control playback.
QUICK SETUP GUIDE
Bluetooth
Speaker
NS-CSPBTF1
V3 ENGLISH 16-0397
TAKING A PHONE
CALL
The following functions are available
when paired to a phone with Bluetooth:
• Reject an incoming call: Press and hold
(call).
• Answer an incoming call: Press
(call).
• Switch audio between your speaker
and phone: Press and hold (call).
• End current call: Press (call).
• Redial the last dialed number: Press
(call) twice.
LED INDICATORS:
TROUBLESHOOTING
Unable to pair.
• Turn your speaker off, then back on.
• If a passcode is needed, enter 0000.
• Move your speaker and Bluetooth device
closer together.
Static or breaks while playing audio.
• Move your speaker and Bluetooth device
closer together.
• Use a paper clip to press reset.
• Make sure that the audio cable is
connected securely.
• Try a different audio cable.
No sound.
• Turn up the volume on both your speaker
and connected device.
• Make sure that your Bluetooth device is
paired to your speaker.
• Unplug the audio cable (if connecting
with Bluetooth).
No power.
• Make sure that your speaker is fully
charged.
Unable to operate.
• Use a paper clip to press reset.
LED
Blinks blue
quickly
Lights solid
blue
Blinks blue
slowly
Lights red
FUNCTION
Bluetooth pairing mode
Paired to a Bluetooth
device
Connected to an
AUX device
Speaker is charging
(charging complete
when LED turns off)
LEGAL NOTICES
lf at any time in the future you
should need to dispose of this
product, note that waste electrical
products should not be disposed of
with household waste. Recycle where facilities
exist. Check with your Local Authority or retailer
for recycling advice. (Waste Electrical and
Electronic equipment Directive)
Owing to continuous improvement, no prior
notice will be given regarding changes on
features and specifications.
FCC Statement
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following two
conditions: (1) this device may not cause
harmful interference and (2) this device must
accept any interference received, including
interference that may cause undesired
operation.
FCC Caution
Changes or modifications not expressly
approved by the party responsible for
compliance could void the user’s authority to
operate this equipment.
Note: This equipment has been tested and
found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide
reasonable protection against harmful
interference in a residential installation. This
equipment generates, uses and can radiate
radio frequency energy and, if not installed and
used in accordance with the instructions,
maybe cause harmful interference to radio
communications. However, there is no
guarantee that interference will not occur in a
particular installation. If this equipment does
cause harmful interference to radio or
television reception, which can be determined
by turning the equipment off and on, the user
is encouraged to try to correct the interference
by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the
equipment and receiver.
• Connect the equipment into an outlet on a
circuit different form that to which the
receiver is connected.
• Consult the dealer or an experienced
radio/TV technician for help.
Industry Canada Compliance
IC Statement
This device complies with Industry Canada’s
licence-exempt RSSs. Operation is subject to
the following two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference,
including interference that may cause
undesired operation of the device.
Conformité à Industrie Canada
Déclaration d'IC
Le présent appareil est conforme aux CNR
d'Industrie Canada applicables aux appareils
radio exempts de licence. L'exploitation est
autorisée aux deux conditions suivantes :
(1) l'appareil ne doit pas produire de
brouillage, et (2) l'utilisateur de l'appareil doit
accepter tout brouillage radioélectrique subi,
même si le brouillage est susceptible d'en
compromettre le fonctionnement.
ONEYEAR LIMITED
WARRANTY
Visit www.insigniaproducts.com for details.
CONTACT INSIGNIA:
For customer service, call 1-877-467-4289
(U.S. and Canada) or 01-800-926-3000
(Mexico)
www.insigniaproducts.com
INSIGNIA is a trademark of Best Buy and its affiliated
companies. Distributed by Best Buy Purchasing, LLC
©2016 Best Buy. All rights reserved. Made in China
