C-ML

Microphone

Element

DESCRIPTION

C-ML

AUDIO MONITORING SYSTEM

INSTALLATION AND OPERATING INSTRUCTIONS

6955 VALJEAN AVE, VAN NUYS, CA 91406

PH: (818)994-6498 / FAX: (818)994-6458

/ www.louroe.com

techsupport@louroe.com

The Model C-ML is an omni-directional, low impedance, electret condenser microphone with level audio. It is

housed in a high impact ABS tube designed for mounting in special or customized housing. Normal pick-up pattern is

approximately 15' from the microphone location, all directions, or within 30' diameter circle. The unit comes with 20’

pre-made cable with a stereo plug on one end that can be plug directly to the Audio Input of an IP camera.

mic

SPECIFICATIONS

Sensitivity

Frequency response

Output Impedance

Current drain

50 Hz to 8 kHz

Supply voltage

Microphone housing High impact ABS

Dimensions

Weight

Shipping Weight

0.455” dia

4.5 oz

1 lb

-45 dB/pa

1kW

0.8mA

1.8Vdc to 4.5Vdc

C_ml_inst_12/14

INSTALLATION AND OPERATING INSTRUCTIONS

LOUROE ELECTRONICS 6 9 5 5 VA L J E A N AVENUE, VAN NUYS, CA 91406 TEL (818) 994-6498 FAX 994-6458

website: www.louroe.com e-mail: sales@louroe.com

(818)

MICROPHONE CONNECTION

Connect the other end of the cable with a 3.5mm Stereo

Plug to the Audio Input of the IP camera.The camera

has to be configured to Mic level settings.

IMPORTANT NOTICE

When this equipment is used as part of an

audio monitoring system, the law requires

that the public be given notice of AUDIO

MONITORING ON THE PREMISES. A

decal notice is included with each

microphone shipped.

Federal Law References:

Federal Regulations, US Code, Title 18.

Crime and Criminal Procedure, Sec 2510.

AUDIO

MONITORING

Thes e Premis es

WARRANTY

LOUROE ELECTRONICS warrants that at the time of shipment products manufactured by LOUROE ELECTRONICS to be free of defects in material and workmanship.

Should a defect appear within one year (12 months) from date of shipment, LOUROE ELECTRONICS will, at its sole discretion, repair or replace the defective equipment.

This equipment shall not be accepted for repair or return without prior notification by LOUROE ELECTRONICS .

This warranty does not extend to any Louroe product that has been subjected to improper or incorrect installation, misuse, accident, or in violation of installation

instructions provided by LOUROE ELECTRONICS.
