DESCRIPTION
SPEAKER CONNECTION OF TLO
MICROPHONE CONNECTION OF TLO
The TLO is a two-way speaker with microphone and re-entry horn for high volume
penetration. Weatherized for outdoor use, it is a microphone and speaker within one
housing. In operation, the TLO provides both listen and talkback capabilities
between the remote zone and Louroe base station, or with other compatible audio
receiving devices such as Louroe AOP-SP70.
MODEL TLO
Speaker connection is located near the rear of the TLO and has a plexiglass window. Remove window and connect the
speaker portion of West Penn 356 (green and white wires) to the two terminal screws marked 1 and 2.
Green speaker wire goes to position 2 (positive)
White speaker wire goes to position 1 (negative)
The short cable extending from the back of the TLO is the microphone connection and consists of three wires: red, black
and bare. Using recommended wiring (West Penn 356 or equivalent), make microphone connections using 20 gauge
wire nuts, and matching wire with , with and wire with wire. See diagram page 2. black black
red red bare
bare
bare
bare
bare bare
bare
bare
bare
bare
see diagram below
POWER TAP SETTINGS
Located above the speaker connection is a set screw with a dial numbered 1 through 7. Using a small screw
driver, adjust the set screw to correspond to the proper power tap setting with the following Louroe audio base
stations.
IF TLO IS CONNECTED TO BASE STATION MODELS:
AP-1TB through AP-16TB #1 1.8W
DG 12 and DG 25 1 TLO per zone #4 15.0WII III
2-4 TLO’s per zone using MLA-6 Mixer #2 3.7W
If TLO is to be connected to Louroe AOP-SP70 conversion unit #2 3.7W
for interfacing with a DVR or PC Soundcard, use setting
Setting Wattage
12
1
2
3 5
6
7
Speaker connection
(WHITE-negative)
Speaker connection
(GREEN-positive)
1 through 7
power tap settings
set screw
WIRING REQUIREMENTS
4 Conductor consisting of:
+2 Conductor , shielded
20 gauge with 22 gauge drain
(microphone connection)
+2 Conductor
unshielded, 18 gauge (speaker
connection)
West Penn 356 or equivalent
TLO
OUTDOOR SPEAKER/MICROPHONE
INSTALLATION AND OPERATING INSTRUCTIONS
Page 1 of 4 tlo inst 3/15
6955 VALJEAN AVE, VAN NUYS, CA 91406
PH: (818)994-6498 / FAX: (818)994-6458
/ www.louroe.com
techsupport@louroe.com
®
CONNECTING TLO TO A LOUROE BASE STATION
POSITIONING TLO
Model TLO is compatible with all Louroe™ audio base stations that feature two-way talk/listen communication. All
Louroe™ base stations contain terminal blocks for receiving both microphone and speaker connections from Model
TLO. For wiring and installation instructions, please refer to the specific Louroe™ Base Station being used.
After TLO has been mounted to desired structure (wall, pole, etc.), horn should be tilted in a downward position.
This will protect the microphone element from water damage.
12
1
2
3 5
6
7
Speaker terminal screws
green wire to #2 (positive +)
white wire to #1 (ground -)
to Louroe base station
Refer to the specific base station instructions for connections
(C) BARE
(A) RED
(B) BLACK
MICROPHONE
CONNECTION
Connects to
Terminals A, B, C
of Louroe Base
Station
{Green = speaker (positive)
connects to terminal “SP” of base station
White = speaker (negative)
connects to terminal “G” of base station
MICROPHONE
CABLE
MICROPHONE
HOUSING
WHITE
(GROUND)
Microphone connection
using three wire nuts
Red = 12Vdc
Black = Audio Output
Bare = Ground
RED
SPEAKER
BLACK
BARE
GROUND (-) POSITIVE (+)
GREEN
(POSITIVE)
Page 2 of 4
LOUROE ELECTRONICS™ 6 9 5 5 VA L J E A N AVENUE, VAN NUYS, CA 91406 TEL (818) 994-6498 FAX 994-6458
website: www.louroe.com e-mail: sales@louroe.com
(818)
INSTALLATION AND OPERATING INSTRUCTIONS
tlo inst 3/15
EXT
SPKR SPKR
SPKR
EXT
A B C CBA SP Vdc+12
GND
+
INTERCONNECTION DIAGRAM
LOUROE MODEL AOP-SP70 SPEAKERPHONE CONVERSION UNIT,
AND LOUROE MODEL TLO SPEAKER/MICROPHONE
CONNECTION TO
DVR, IP NETWORK CAMERAS OR VIDEO SERVER
(BI-DIRECTIONAL AUDIO)
For connection to DVR, IP Network Camera, etc., solder the appropriate plug (RCA, 3.5mm
mono or 3.5mm stereo) to match the audio inputs of the receiving device as shown below.
Refer to IP Camera’s instruction to determine if 3.5mm audio is mono or stereo
Model TLO is Designed For Outdoor
or Moist Applications
WHITE (SP)
BLACK (C)
(C) BARE
(B) RED
TO AUDIO OUT OF DVR, ETC.
TO AUDIO IN OF DVR, ETC.
West Penn 358
or equivalent
BARE (C)
BLACK (B)
RED (A)
WHITE
WIRE NUTS
GREEN
4 Conductor shielded cable
2 shielded 20 gauge and
2 unshielded 18 gauge,
20 gauge drain wire
West Penn 356 or equivalent
WIRING REQUIREMENTS FOR TLO
MICROPHONE
CABLE
Microphone connection
using three wire nuts
Red = 12Vdc
Black = Audio Output
Bare = Ground
RED BLACK
BARE
WHITE SPEAKER
(GROUND)
GREEN SPEAKER
(POSITIVE)
Audio Out
Audio Out Audio In
Audio In
Bare Wire
Red Wire
RCA CONNECTION
3.5mm MONO CONNECTION 3.5mm STEREO CONNECTION
White Wire
Black Wire
Black Wire
White Wire
Red Wire
Bare Wire
M
M
M
M
M
O
O
O
O
O
N
N
N
N
N
O
O
O
O
O
S
S
S
S
S
T
T
T
T
T
E
E
E
E
E
R
R
R
R
R
E
E
E
E
E
O
O
O
O
O
Audio Out
Audio In
Red Wire
Black Wire
White WireBare Wire
CA
SPB
INSTALLATION AND OPERATING INSTRUCTIONS
LOUROE ELECTRONICS® 6 9 5 5 VA L J E A N AVENUE, VAN NUYS, CA 91406 TEL (818) 994-6498 FAX 994-6458
website: www.louroe.com e-mail: sales@louroe.com
(818)
Using power supply (included), connect as
follows:
Positive 12Vdc connects to terminal marked
“+”
Negative 12Vdc or ground connects to
terminal marked “GND”(wire with white
stripes)
LOUROE MODEL AOP-SP70
tlo inst 3/15
