Alogic UL2QC10CA Käyttöohje
Alogic
Akun laturi
UL2QC10CA
Lue alta 📖 käyttöohje suomeksi merkille Alogic UL2QC10CA (2 sivua) kategoriassa Akun laturi. Tämä opas oli hyödyllinen 4 henkilölle ja sai 4.5 tähden keskimäärin 2 käyttäjältä
Sivu 1/2
Operation Instructions
To commence charging, plug the included power adapter to a power wall socket and
proceed to connect the other end to the Power Hub, located on the back. Two white LED
lights will appear to indicate that the device is on.
For Wireless Charging:
For Wired Charging:
1. LED lights will turn solid white to indicate that the device is in standby mode and is ready
to be used
2. To activate wireless charging, simply place your Qi-enabled devices on the top of the
Power Hub. Make sure that the centre of your device is aligned with one of the Qi logos
on top of the charger.
3. The LED lights will appear to breath slowly to indicate that a successful connection has
been established and wireless charging has commenced.
4. In the event that a foreign object is detected (FOD) or if your device is emitting high
temperatures the LED indicator will flash red.
1. To charge a device via the USB-A port, connect the USB-A end of your existing compat-
ible cable to the Power Hub’s USB-A port and the other end to your device, charging
should commence immediately.
2. To charge a device via the USB-C port, connect the USB-C end of your existing compat-
ible cable to the Power Hub’s USB-C port and the other end to your device, charging
should commence immediately.
Introduction Physical Layout
Features
The Wireless Power Hub Multi-Device Wireless & USB Charging Station acts as a central
charging solution for any shared or personal environment. The Wireless Power Hub features
wireless charging for two Qi-enabled devices such as your smartphone or wireless
earphones, along with two more devices via the USB-C and USB-A ports. The Wireless
Power Hub’s sleek design compliments and integrates into any work or home environment.
FCC Warning
Note
This device complies with part 18 of the FCC Rules. Operation is subject to the following
two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
Any changes or modifications to this unit not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment
• Declutter your space by charging up to four devices with a single cable input
• Wireless charging supports up to 10W and is also optimised with 7.5W for iPhones for the
most optimum charging speeds
• USB-C port with up to 18W (Power Delivery) output to fast charge your latest USB-C
enabled devices
• USB-A port with up to 7.5W output to charge any mobile device
• Qi-enabled accessories such as wireless earphones can also be charged wirelessly via
the charging pad.
• Crafted from aluminium and fabric to create an elegant look while maintaining durability
• LED charging indicators for an at glance status
• Foreign object detection (FOD) indicators
Package Contents
1 x Wireless Power Hub Multi-Device Wireless & USB Charging Station
1 x Power Adapter
1 x AU/EU/UK/US Plug Set
1 x User Manual
Specifications
Model UL2QC10CA-SGR
Input DC Input 100-240V ~ 5/60Hz, 1.5A
Output 1 x USB-A (7.5W), 1 x USB-C (18W PD), 2 x 10W Wireless charging
Power
USB-C Port Up to 18W Power Delivery
USB-A Port Up to 7.5W
Wireless Charging Pad 10W/ 7.5W/ 5W
Wireless Charging Pad
USB-C Power Output
USB-A Power Output
LED Indicators
DC Power Input
1
3
5
2
4
1
2
3 54
Tuotetiedot
| Merkki: | Alogic |
| Kategoria: | Akun laturi |
| Malli: | UL2QC10CA |
