Do not spec or install speaker near support beam, ventilation duct or
other structure that may interfere with speaker function or dispersion.
Warning Warning
SoundTu s m s by a pr s n s r r r. r s y and r be peakers ust be in talled ofes io al audio in talle /cont acto Fo afet fo
optim dio performa ce, talle follow all di ection sued nd be nte taium au n ins r t mus r s is by Sou Tu E r nment.
Mo tiun ng bracket
Speaker
Box contents
1 Speaker
Optional accessories
The SM31-EZ has 2 optional
accessories: a junction box
mounting plate (AC-SM31-MP)
and a junction box mounting
plate with a transformer
(AC-SM31-XFMR).
© 2010 SoundTube Ente ai enrt nm t, In llc. A rig tsh rese edrv . PN INS-S 31-M EZ R ev05.10.10
Insta s nll In tr tiouc s For:
SM31-EZ speaker
SM31-EZ
1. Unpack speaker.
5. Attach speaker to surface
using installer-supplied
fasteners.
6. Aim speaker by pointing it
up or down and/or rotating
it.
3b. If mounting speaker
offset from wiring point, run
wire out hole in wall and
behind base plate through 2
mm standoff gap between
base plate and wall.
Standoff gap accepts up to
18-gauge flat signal wire.
4. Choose a secure
mounting surface with
sufficient strength to reliably
hold the speaker.
3a. If mounting speaker
directly over wire, ensure
base plate covers hole in
wall.
7. e!Don
2. Connect speaker wire
leads to terminal screws on
back of base plate. Polarity
is indicated
SM31-EZ
Installation Instructions For:
SM31-EZ speaker
1.435.647.9555
| | 800.647.TUBE
www.soundtube.com
Do not spec or install speaker near support beam, ventilation duct or
other structure that may interfere with speaker function or dispersion.
Warning Warning
SoundTu s m s by a pr s n s r r r. r s y and r be peakers ust be in talled ofes io al audio in talle /cont acto Fo afet fo
optim dio performa ce, talle follow all di ection sued nd be nte taium au n ins r t mus r s is by Sou Tu E r nment.
Single-gang junction box
(NOT INCLUDED)
Transformer module
Speaker fasteners
Wall plate fasteners
***Junction Box Requirements***
Minimum 2.5-inch deep, single-gang, new construction junction box required.
Unit will fit in retrofit-style junction box. NOT
SoundTube recommends testing fit before installing junction boxes.
Box contents
1 Transformer module
2 Fasteners for speaker to wall plate
2 Fasteners for wall plate to junction box
© 2010 So ndu Tube Ente airt nment, I .nc All rights rese ver d. I MNS-S 31-X MRF Rev 05 0.21.1
Inst trua sll In ctions For:
AC-SM31-XFMR transformer option
AC-SM31-XFMR Transformer
