INSTRUCTION MANUAL
MAG6R 6.5” 2-WAY SPEAKERS
• The speaker’s positive post is labeled with a red dot; the
negative post is labeled with a blackdot Double-check that
you connected amplifier “+” to speaker “+” and amplifier “–”
to speaker “–”.
3. Make sure all the Roto-Lock clamps are retracted so that
they are tucked within the mounting hole’s border. Insert the
speaker into the hole in the ceiling. The Roto-Lock system
can accommodate a maximum ceiling material thickness of
1 1/4”(32mm).
4. Tighten the four screws on the front of the speaker bae.
The Roto-Lock clamps will automatically rotate into position
and begin clamping the speaker. When you notice resistance
on the screws the speaker has been clamped successfully.
IMPORTANT: Always use low-torque settings;
NEVER over-tighten.
NOTE: ADJUSTING THE TENSION OF THE ROTO-LOCK
CLAMPS SO THAT THE SPEAKER FRAME IS FLAT WILL
HELP ENSURE THAT THE GRILLE CONTACTS THE CEILING
ALL THE WAY AROUND THE SPEAKER FOR A PROPER FIT.
5. The micro-trim grille is held in place by several small,
powerful magnets on the speaker frame. Place the grille
against the speaker and the magnets will hold it firmly in
place. When properly installed, the grille trim should make
contact with the wall all the way around the speaker.
SPEAKER ADJUSTMENTS
Pivoting Woofer and Tweeter
Pivoting drivers allow you to direct sound towards or away
from the listening area, depending on how the speakers are
being used:
• If you’re using the speakers in stereo or as the front left/
center/ right speakers in a home theater, pivot the woofer
and/or tweeter directly towards the listening area. This will
help the sound from the speakers blend into a solid sound
stage even if the speakers are widely separated.
• If you’re using the speakers as surround channel speakers in
a home theater, you can create a more diuse, spacious
surround eect by pivoting the woofer and/or tweeter
towards a wall or window, away from the listeners.
To Pivot the Tweeter:
Apply light pressure to the plastic ring around the outside
edge of the tweeter dome. Do not touch or apply pressure to
the tweeter dome itself.
To Pivot the Woofer:
Apply pressure on the outer edge of one of the tweeter
support brackets. Do not touch or apply pressure to the
woofer cone.
INTRODUCTION
Thank you for purchasing MAG6R speakers. When properly
installed your new speakers will give you years of
entertainment pleasure.
BOX CONTENTS
In-ceiling speaker box contains (2) MAG6R Speakers,
(2) paintable grilles and mounting cut-out templates.
STEREO PLACEMENT
2-Channel
• Place the left and right speakers 6 - 10 feet (1.8m – 3m)
apart, with the main listening position as close to midway
between the speakers as possible.
• In most cases pivoting the woofer of each speaker directly
towards main listening position will help maximize the
stereo soundstage.
BEFORE INSTALLATION
1. Determine the location for the speaker.
2. Perform an obstruction survey using a stud finder to be
certain that there are no studs, conduit, pipes, heating,
ducts, pocket doors or air returns in the ceiling cavity that
will interfere with the speaker. If you are unsure about
obstructions, drill a small hole in the center of the outline and
insert a coat hanger wire into the hole to feel around for
possible obstructions.
3. Mounting Space Requirements:
• 8 1/4” (210mm) diameter cut-out; 4 3/4” (121mm) depth
within the mounting cavity.
4. Position the included cut-out template where the speaker
is to be located and pencil an outline on the ceiling.
5. Cut the mounting hole using a keyhole or drywall saw and
run the speaker wires from the mounting hole to the
amplifier location.
NOTE: CONSULT LOCAL BUILDING CODES BEFORE
RUNNING SPEAKER WIRES THROUGH CEILINGS.
INSTALLATION
MAG6R speakers feature an exclusive, integral Roto-Lock®
mounting system for quick mounting directly into existing
ceilings.
1. Strip 1/4”-1/2” (6mm – 12mm) of insulation from each
speaker lead. Twist the strands or tin the exposed wire with
solder to ensure that there are no stray strands. (Stray strands
that touch each other can cause a shortcircuit that can
damage the amplifier.)
2. The speaker’s connector posts are spring-loaded. Push the
top of each connector post down to open the connector and
insert the exposed wires into the holes in the posts.
MAG6R
Frequency Response: 45Hz - 20kHz 3dB±
Impedance: 8 ohms nominal; 6 ohms minimum
Power Handling: 5 watts minimum, 125 watts maximum
01.29.20
©2020 Sonance. All rights reserved.
Sonance and FastMount are registered trademarks of Sonance.
Due to continuous product improvement, all features and specifications are subject to change without notice.
For the latest Sonance product specification information visit our website: www.sonance.com.
SONANCE • 991 Calle Amanecer • San Clemente, CA 92673 USA
PHONE: (949) 492-7777 • FAX: (949) 361-5151 • Technical Support: (949) 492-7777
www.sonance.com
LIMITED ONE (1) YEAR WARRANTY
Sonance warrants to the first end-user purchaser that this Sonance-brand product (“Product”), when purchased from an
authorized Sonance Dealer/Distributor, will be free from defective workmanship and materials for the period stated below.
Sonance will at its option and expense during the warranty period, either repair the defect or replace the Product with a new
or remanufactured Product or a reasonable equivalent.
EXCLUSIONS
TO THE EXTENT PERMITTED BY LAW, THE WARRANTY SET FORTH ABOVE IS IN LIEU OF, AND EXCLUSIVE OF, ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED, AND IS THE SOLE AND EXCLUSIVE WARRANTY PROVIDED BY SONANCE. ALL OTHER
EXPRESS AND IMPLIED WARRANTIES, INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY, IMPLIED WARRANTY
OF FITNESS FOR USE, AND IMPLIED WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE ARE SPECIFICALLY EXCLUDED.
No one is authorized to make or modify any warranties on behalf of Sonance. The warranty stated above is the sole and
exclusive remedy and Sonance’s performance shall constitute full and final satisfaction of all obligations, liabilities and claims
with respect to the Product.
IN ANY EVENT, SONANCE SHALL NOT BE LIABLE FOR CONSEQUENTIAL, INCIDENTAL, ECONOMIC, PROPERTY, BODILY
INJURY, OR PERSONAL INJURY DAMAGES ARISING FROM THE PRODUCT, ANY BREACH OF THIS WARRANTY OR
OTHERWISE.
This warranty statement gives you specific legal rights, and you may have other rights which vary from state to state. Some
states do not allow the exclusion of implied warranties or limitations of remedies, so the above exclusions and limitations may
not apply. If your state does not allow disclaimer of implied warranties, the duration of such implied warranties is limited to
period of Sonance’s express warranty.
Your Product Model & Description: Sonance MAG6R speakers
Warranty Period for this Product: One (1) year from the date on the original sales receipt or invoice or other satisfactory proof
of purchase.
ADDITIONAL LIMITATIONS AND EXCLUSIONS
FROM WARRANTY COVERAGE
The warranty described above is non-transferable, applies only to the initial installation of the Product, does not include
installation of any repaired or replaced Product, does not include damage to allied or associated equipment which may
result for any reason from use with this Product, and does not include labor or parts caused by accident, disaster, negligence,
improper installation, misuse (e.g. overdriving the amplifier or speaker, excessive heat or cold or humidity, outdoor installation),
or from service or repair which has not been authorized by Sonance.
OBTAINING AUTHORIZED SERVICE
To qualify for the warranty, you must contact your authorized Sonance Dealer/Installer or call Sonance Customer Service at
(949) 492-7777 within the warranty period, must obtain a return merchandise authorization number (RMA), and must deliver
the Product to Sonance shipping prepaid during the warranty period, together with the original sales receipt, or invoice or other
satisfactory proof of purchase.
